User's Manual of netMod Network Termination Unit

Indicators

There are six LEDs on the non-removable cover (see Figure 6), described in the table
below:
LED
M.P.
R.P (Remote
Power)
LINK
B1/B2
USB
STATUS
Orange
OFF
Continuously ON (green)
OFF
Flashing green (Fast)
Flashing green (Slow)
Continuously ON (green)
OFF
Flashing green
Flashing red
Flashing yellow
OFF
Continuously ON (green)
Flashing (green)
FUNCTION
netMod is powered by mains
Absence of mains power
Remote Power from ISDN Exchange. netMod is
powered by mains power.
No Remote Power from ISDN Exchange
Upgraded software version has been downloaded.
netMod is powered by Mains power.
Upgraded software version has been downloaded.
netMod is powered by Remote Power only
(Emergency mode)
The U-link is fully synchronised
The U-link is not synchronised
B channels are occupied (voice)
B channels are occupied (data)
B channels are occupied by a terminal connected on
the S-bus (ISDN telephone, ISDN external TA)
B channels are not occupied
The communication between the netMod and the PC
has been established
Data transfer is activated

Figure 6: netMod's LEDs

14
