&ZI?
&ZO?
&ZON=X

Extended AT! Command set (AO/DI - X.25 Functionality)

Command Option
!X0=n n = 0 – 63
!X1=n n = 0 - 255
!X2=xxx xxx = X.121
address
(Max.15 digits)
!X3=n n = 1 – 7
!X4=n n = 1 - 7
!X5=n n = 0 – 3
0
1
2
3
!X6=xxx xxx = 0 - 255
!X7=xxx xxx = 4 - 256
!X8=n n = 0 - 15
!X9=n n = 0 - 15
!X10=n n = 0 - 255
!X11=n n = 0 – 100
!X12=n n = 0 – 255
!X13=n n = 0 – 64
!X14=n n = 0 – 255
!X15=n n = 0 – 64
!X16=n n = 0 – 255
!X17=n n = 0 – 64
!X?
!P
Display the phone number for port ab1, port ab2 & DTE Port.
Display the own phone number for port ab1, port ab2 & DTE Port.
Write own phone number X. The number specified will be used as the calling
party number while dialling (in the outgoing SETUP message).
Values for "N"
I = for DTE port
a = analogue adapter, ab1
b = analogue adapter, ab2
Function and description
Set TEI (Terminal Endpoint Identifier)
Set LCN (Logical Channel Number)
Set X.121 address
Set Layer 2 window size
Set Layer 3 window size
Restart Request Wait after L2 activation
None
1 second
5 seconds
20 seconds
Set CUG (Closed User Group) identifier (255 = no CUG)
Set packet size (must always be multiple of 2)
X.121 number of address prefix digits.
X.121 number of address postfix digits.
Add persist time interval for D channel in seconds (Default value is 5
seconds)
Add threshold as a percentage of the total 9600 bits/sec (e.g n=40%,
50%, 60% e.t.c) value must be assigned without "%" sign.
Sub persist time for the First B channel. Value is assigned in seconds
(Default value is 60 seconds).
Sub threshold rate for the first B channel. Value is assigned in kbits/sec.
(Default value is 4 kbits/sec).
Add persist time for the first B channel. Value is assigned in seconds.
(Default value is 20 seconds).
Add threshold rate for the first B channel. Value is assigned in kbits/sec.
(Default value is 52 kbits/sec).
Sub persist time for the second B channel. Value is assigned in seconds.
(Default value is 40 kbits/sec).
Sub threshold rate for the second B channel. Value is assigned in
kbits/sec. (Default value is 48 kbits/sec).
By typing this command you can see all the parameters of X.25 (including
AO/DI).
Enable PAD (Packet Assembler Dissembler) mode in X.25
65
