5.

Calling Line Identification Presentation

5.1.

Calling Line Identification Presentation (ON HOOK CLIP)

Calling Line Identification Presentation is a service offered to the called subscriber and
presents the calling party's number before answering the call (ON HOOK). In the display of
the called subscriber's telephone set, appears the number of the calling subscriber. This
service is implemented by means of FSK signalling on netMod's analogue ports. The
called subscriber should have the proper terminal device that transforms the FSK
signalling to a visual indication (e.g. INTRACOM'S IRIS 6020-CID).
Note that if the CLIP service is available to the subscriber, netMod initially allows the
forwarding of the calling subscriber number through FSK signalling, to the called
subscriber terminal device connected to the analogue ports ab1 and ab2.
• By pressing the keys
on each of netMod's analogue port ab1 or ab2.
• By pressing the keys
separately on each of netMod's analogue port ab1 or ab2.
Note that this service is initially activated on both analogue ports
of netMod.
5.2.

Setting the Own Number

The calling subscriber can define which of the MSN numbers assigned to each analogue
port will be presented on the called subscriber when he makes a call from the specified
port by pressing the following keys combinations:
**90*MSN#
5.3.

Calling Line Identification Presentation (OFF HOOK CLIP or CLIP on CW)

This service allows the called subscriber to identify the calling subscriber, during off hook
state. Activating this service, the subscriber that has already answered a call is able to
identify all the new incoming calls (Waiting Calls).
• By pressing the keys
netMod's analogue port ab1 or ab2.
• By pressing the keys
netMod's analogue port ab1 or ab2.
Note that this service is initially deactivated on both analogue
ports of netMod.
*85#
the transmission of the CLIP signal is activated, separately
#85#
the transmission of the CLIP signal is restricted,
*84#
the transmission of the CLIP signal is activated on each of
#84#
the transmission of the CLIP signal is restricted on each of
25
User's Manual of netMod Network Termination Unit
