Calling Line Identification Presentation (CLIP)

Using AT Commands the called subscriber can write the proper value on the S84-Register
to allow / restrict the presentation of the calling party number on both analogue netMod's
ports.
ATS84=0 allows the forwarding of the calling party number to the called subscriber's
terminal devices connected to the analogue ports ab1 and ab2, in OFF HOOK and ON
HOOK state.
ATS84=190 restricts the forwarding of the calling party number to the called subscriber's
terminal devices connected to the analogue ports ab1 and ab2 when OFF HOOK, and
allows the forwarding of the calling subscriber's number when ON HOOK.
ATS84=240 restricts the forwarding of the calling party number to the called subscriber's
terminal devices connected to the analogue ports ab1 and ab2 either in OFF HOOK or in
ON HOOK state.
The calling subscriber can define which of his/her multiple subscriber numbers (MSN)
defined on each port will appear on the called subscriber's device, when he / she initiates
calls from the specified port.
Type the following commands:
at&zoa= MSN number, for the analogue port ab1
at&zob= MSN number, for the analogue port ab2
at&zoi= MSN number, for the data port
The above settings are stored permanently in netMod's memory. If the calling subscriber
does not make the above assignments for each port, then by making a call from that
specific port, the basic subscriber number defined for this BRA access will appear on the
called subscriber's devices.
Using AT Commands write on the S82-Register the proper value, to allow the presentation
of the calling party number on the screen of your communication program (e.g. Hyper
Terminal) on your PC.
ATS82=76 allows the presentation of the calling party number on the monitor of your PC.
To restore the proper functionality and to be connected to the Internet by using the PPP or
ML-PPP protocol, give the command:
ATS82=74, that allows the restoration of the proper functionality for the connection to the
Internet.
In order to be connected to the Internet, write on the S82-Register
the value 74.
