Use the Hyper Terminal communication program of Windows' 95/98Me to update
netMod's software, by following the steps given below:
•
Open the <HyperTerminal> program on Windows' 95/98/Me.
•
On the <Connection Description> window enter a name and then press <OK>.
•
On the <Phone Number> window assign a number and select <Connect> using <Direct
to Com1> or <Direct to Com2> depending on the PC's communication port connected
to netMod and press <OK>.
•
On the next window <Port Setting> select:
Bits per second:
Data bits:
Parity:
Stop bits:
Flow Control:
•
Press <OK>.
•
On the <HyperTerminal> window type: at
netMod will answer OK.
•
Type: atupx
netMod will give a message for updating the software.
•
Type: Y
netMod will reset the previous version.
•
Once you receive the OK message, select from the main menu <Transfer> and then
<Send file>.
•
On the next window <Send file> select the <Xmodem Protocol> and then browse to
find the file that you want to download.
•
Select the file XXXX.dnl that corresponds to your device and on the window <Send
file> select <Send>.
•
Wait for a few seconds.
On the window <Xmodem file send>, you will notice that the data packets and the size of
the file that is being downloaded are increasing.
Once you finish the update, wait for a few seconds and then:
•
Type: ati3
netMod will return the version of the new software.
netMod is now equipped with the new software.
115200
8
None
1
Hardware
