TECHNICAL CHARACTERISTICS

U-line
♦ In compliance with
♦ Line code
♦ Output Level
♦ Carrier
♦ Bit rate
♦ Net bit rate
♦ Interface
S-bus
♦ In compliance with
♦ Line code
♦ Output Level
♦ Carrier
♦ Bit rate
♦ Interface
a/b Line
♦ In compliance with
♦ Dialling
♦ Voice encoding
♦ VF output level
♦ VF input level
♦ Subscriber loop voltage
♦ Subscriber loop current
♦ Line termination
impedance
♦ Ringing frequency
♦ Charging Pulses
♦ Interface
♦ CLIP supplementary
service according to
User's Manual of netMod Network Termination Unit
: ETSI ETR 080
: 2B1Q
: 2.5V peak at 135Ω Load
: twisted copper pair
: 160 kbps
: 144 kbps
: Telephone jack (RJ-11)
: ETSI 300 012, ITU-T.430
: AMI
: 750mV peak
: 4-wire passive bus
: 192 kbps
: telephone 8-pin jack connector (RJ-45)
: ITU-T Q.552
: DTMF/Pulse signalling
: A-law PCM
: -7dBr
: 0dBr
:
ON-HOOK: 48V (±2V)
≥20 mA
:
: 600 ohm
: 25Hz
: 16kHz
: telephone jack (RJ-11)
: ETS 300 089, ETS 300 659-1, V.23 signalling
