Conventions

Table 2 provides the conventions used for the ON and OFF settings in the present
document.
Convention
Jumper JPx ON
Jumper JPx OFF
Solder bridge SBx ON
Solder bridge SBx OFF
In this document the reference is "STM32 Nucleo-32 board" for all information that is
common to all sale types.

Table 2. ON/OFF conventions

Jumper fitted
Jumper not fitted
SBx connections closed by solder or 0 ohm resistor
SBx connections left open
