- Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS Elise 90 Dual Fuel Australia U111113-01...
-
Page 2: Table Of Contents
Contents Before You Start... Troubleshooting Personal Safety Service and Spares Electrical Connection Safety Installation If You Smell Gas Peculiar Smells Positioning the Range Cooling Fan When Fitting Between Kitchen Cabinets Ventilation Moving the range Maintenance Lowering the two rear rollers Grill/Glide-out Grill™... -
Page 3: Before You Start
Before You Start... Your cooker should give you many years of The cooker should not be placed on a base. • trouble-free cooking if installed and operated This appliance is designed for domestic • correctly. It is important that you read this cooking only. -
Page 4: Electrical Connection Safety
Always keep combustible materials, e.g. Make sure that the gas supply is turned • • curtains, and flammable liquids a safe on and that the cooker is wired in and distance away from the cooker. switched on. DO NOT spray aerosols in the vicinity of In your own interest and that of safety, it is •... -
Page 5: Ventilation
NEVER leave the hotplate unattended Ventilation • at high heat settings. Pans boiling over The use of a cooking appliance results in the can cause smoking, and greasy spills may production of heat and moisture in the room catch on fire. Use a deep fat thermometer in which it is installed. - Page 6 DO NOT modify this appliance. This • Fig. 1.1 appliance is not intended to be operated by means of external timer or separated remote-control system. If flammable materials are stored in the • ArtNo.324-0001 Steam burst drawer, oven(s) or grill(s) it may explode and result in fire or property damage.
-
Page 7: Grill/Glide-Out Grill™ Care
DO NOT use the timed oven if the Cooker Care • adjoining oven is already warm. As steam can condense to water droplets DO NOT place warm food in the oven to be on the cool outer trim of the oven, it may be •... - Page 8 DO NOT put the burner heads in a • dishwasher. NEVER use caustic or abrasive cleaners as • these will damage the surface. DO NOT use steel wool, oven cleaning • pads or any other materials that will scratch the surface. NEVER store flammable materials in the •...
-
Page 9: Cooker Overview
Cooker Overview DocNo.020-0006 - Overview - 100DF - Prof+ Fig. 2.1 The 90 dual fuel cooker (Fig. 2.1) has the following features: Fig. 2.2 Four hotplate burners with one wok burner Control Panel Glide-Out Grill™ Multifunction Oven Tall Fan Oven Hotplate Burners The drawing by each of the central knobs indicates which burner that knob controls. -
Page 10: Wok Burners
The igniter should spark and light the gas. Keep holding the Fig. 2.3 knob pressed in to let the gas through to the burner for about ten seconds. If, when you let go of the control knob, the burner goes out, then the FSD has not been bypassed. -
Page 11: The Wok Cradle
The Wok Cradle Fig. 2.9 The wok cradle is designed to fit a 35 cm wok. If you use a different wok, make sure that it fits the cradle. Woks vary very widely in size and shape. It is important that the wok sits down on the pan support –... -
Page 12: The Glide-Out Grill™ (Fig. 2.14)
The Glide-out Grill™ (Fig. 2.14) Fig. 2.14 WARNING: When the trivet has been removed from the grill pan, please ensure that the grill pan and cradle are fully returned into the grill chamber. The grill pan door MUST remain open. Accessible parts may be hot when the broiler is in use. -
Page 13: The Fan Oven
The Fan Oven Fig. 2.15 The right-hand oven is a fan oven that circulates hot air continuously, which means faster, more even cooking. The recommended cooking temperatures for a fan oven are generally lower than a conventional oven. NOTE: Please remember that all cookers vary so temperatures in your new ovens may differ to those in your previous cooker. -
Page 14: Multifunction Oven Functions
Multifunction Oven Functions Conventional Oven (Top and Base Heat) This function combines the heat from the top and Fan Oven base elements. It is particularly suitable for roasting and baking pastry, cakes and biscuits. This function operates the fan and the heating element around it. -
Page 15: Accessories
Accessories Fig. 2.19 Shelf guard Oven Shelves – Left-hand (Main) Oven The oven shelves (Fig. 2.19) can be easily removed and refitted. Pull the shelf forward until the back of the shelf is stopped by Front the shelf stop bumps in the oven sides (Fig. 2.20). Lift up the front of the shelf so the back of the shelf will pass Fig. -
Page 16: Using The Glide-Out Grill
Using the Glide-out Grill™ DocAUS.020-0004 - Overview - 110DF - Elan Fig. 3.2 Fig. 3.1 Nearest to the element Middle High Middle Low Furthest from the element Four grill height positions refer to Fig. 3.5 Fig. 3.4 Fig. 3.3 To switch on both elements To switch on the right half element Four grill height positions Fig. -
Page 17: Cooking Tips
English Cooking tips Cooking with a multifunction oven General oven tips Remember: not all modes are suitable for all food types. The The wire shelves should always be pushed firmly to the back oven cooking times given are intended for a guide only. of the oven. -
Page 18: Cooking Table
Cooking Table The oven control settings and cooking times given in the table below are intended to be used as a guide only. Individual tastes may require the temperature to be altered to provide a preferred result. Top (T) ArtNo.050-0007 Centre (C) Food is cooked at lower temperature in a fan oven than in a conventional oven. -
Page 19: Cleaning Your Cooker
Cleaning your cooker Essential Information Fig. 6.1 Isolate the electricity supply before carrying out any thorough cleaning. Allow the cooker to cool. NEVER use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. DO NOT mix different cleaning products –... -
Page 20: The Griddle Plate (Optional)
The Griddle Plate (optional) Fig. 6.5 ArtNo.331-0003 Grill frame out, no pan Always clean the griddle plate after use. Allow it to cool completely before removing. Immerse the griddle plate in hot soapy water. Use a soft cloth or, for stubborn stains, a nylon washing up brush. -
Page 21: Ovens
Ovens Fig. 6.8 ‘Cook & Clean’ Panels The main oven has panels which have been coated with a special enamel that partly cleans itself. This does not stop all marks on the lining, but helps to reduce the amount of manual cleaning needed. -
Page 22: Cleaning Table
Cleaning table Cleaners listed are available from supermarkets or electrical retailers as stated. For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish Recommended Cleaning Method... -
Page 23: Troubleshooting
Troubleshooting Hotplate/Cooktop ignition or hotplate burners faulty Food is cooking too slowly, too quickly, or burning Is the power on? If not, there maybe something wrong with Cooking times may differ from your previous oven. the power supply. Check that you are using the recommended temperatures Are the sparker (ignition electrode) or burner slots blocked by and shelf positions –... - Page 24 Oven light is not working Fig. 7.1 The bulb has probably burnt out. You can buy a replacement bulb (which is not covered under the warranty) from a good electrical shop. Ask for a 40 W – 230 V halogen lamp (G9) (Fig. 7.1). Turn off the power at the circuit breaker.
-
Page 25: Service And Spares
Please Note For warranty information and how to request a remedy, please refer to the Warranty Statement at www.andico.com.au/customer-care/falcon or contact Customer Care. Out of Warranty We recommend that our appliances are serviced regularly throughout their life to maintain the best performance and efficiency. -
Page 26: Installation
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Installation Location of range Checking the parts: The range may be installed in a kitchen/kitchen diner but 3 pan supports Wok cradle NOT in a room containing a bath or shower. This appliance is designed for domestic cooking only. -
Page 27: Positioning The Range
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Positioning the Range Fig. 9.1 The diagram (Fig. 9.1) shows the minimum recommended distance from the range to nearby surfaces as given in AS/NZS 5601. Overhead – Measurement A The minimum height of any surface above the range is 650 mm above the hotplate. -
Page 28: When Fitting Between Kitchen Cabinets
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. When Fitting Between Kitchen Fig. 9.4 *Note Cabinets 5mm gap if the appliance is 30mm in front of WORKTOP the kitchen cabinets We recommend that you either: 9mm gap if the appliance is to be flush fitted DOOR CHROME TRIM between kitchen cabinets... -
Page 29: Completing The Move
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Completing the move Fig. 9.6 Unfold the rear edge of the cardboard base tray. Open the oven door(s) so that you can get a good grip on the bottom of the fascia panel as you move the oven (Fig. -
Page 30: Conversion To Another Gas
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Conversion to Another Gas Fig. 9.12 If the appliance is to be converted to another gas do the conversion at this point. See ‘Conversion to LP Gas’ . Gas inlet Gas Connection This must be in accordance with the relevant standards. -
Page 31: Electrical Connection
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Electrical Connection Current Operated Earth Leakage Breakers This appliance must be installed by a qualified electrician to comply with with current AS/NZS 3000 Wiring Rules and The combined use of your range and other domestic regulations in force. -
Page 32: Fixed Wiring
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Fixed Wiring Fig. 9.15 Disconnect from the mains supply. For connection to fixed wiring, i.e. flexible conduit, Remove the electrical terminal cover on the back panel (Fig. 9.15). Remove the M4 screw securing the reducer plates to the conduit box (Fig. -
Page 33: 10. Final Fitting
INSTALLATION Check the appliance is electrically safe when you have finished. 10. Final Fitting Fitting the Handrail Fig. 10.1 Using the 2 mm Allen key supplied, loosen the two Retaining screw retaining screws in the base and side of the handrail support. -
Page 34: 11. Conversion To Lp Gas
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 11. Conversion to LP Gas Conversion from Natural Gas Fig. 11.1 (1.0 kPa) to LPG X Propane (2.54 kPa) A suitably competent person must perform the conversion. -
Page 35: Set The Governor
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Set the Governor Fig. 11.5 Unscrew the governor’s brass top. In the base of the brass top is a plastic snap-in converter device (Fig. -
Page 36: 12. Servicing
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 12. Servicing BEFORE SERVICING ANY GAS CARRYING Fig. 12.1 COMPONENTS TURN OFF THE GAS SUPPLY Check the appliance is gas sound after completion of service. - Page 37 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 2 Hotplate Fig. 12.3 2.1 To remove the hotplate BEFORE SERVICING ANY GAS CARRYING COMPONENTS, TURN OFF THE GAS SUPPLY. Screws DISCONNECT FROM THE ELECTRICAL SUPPLY ! Remove the pan supports and burner heads.
- Page 38 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 2.5 To Replace a Hotplate Burner DISCONNECT FROM THE ELECTRICITY SUPPLY. Remove the hotplate tray (see 2.1). The burners (except the wok burner) are mounted on support struts.
- Page 39 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 4 Grill Fig. 12.6 4.1 To Replace the Grill Controller DISCONNECT FROM THE ELECTRICITY SUPPLY. Remove the control panel and hotplate (see 1.1 &...
- Page 40 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Tall Oven Fig. 12.7 Open the tall oven door and remove the 2 lower screws and washers and remove the upper screw and washer securing the inner back to the back of the oven (Fig.
- Page 41 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. it clear. Fig. 12.11 Fig. 12.12 Remove the 2 screws ‘A’ and allow the plate to drop down (Fig.
- Page 42 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 6.5 To Change the Left Hand Oven Door Latch Fig. 12.17 Fig. 12.16 Remove the outer door panel (see 6.4). Remove screws ‘B’ , which hold the latch assembly to the inner door panel (Fig.
-
Page 43: 13. Circuit Diagram
13. Circuit Diagram P095199 P038434 P095199 The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Description Code Color Blue Grill Front Switch Right Hand Oven Front Switch Brown Grill Energy Regulator Right Hand Oven Fan Element Black... -
Page 44: 14. Technical Data
Operating Pressure at appliance test point Natural Gas 1 kPa Propane 2.54 kPa Dimensions Model Elise 90 Dual Fuel Overall height minimum 910 mm maximum 935 mm Overall width 900 mm Overall depth 598 mm excluding handles, 650 mm including handles...
