3.
Use a cable tie to secure the power cord to the handle of the
power module.
Figure 7 Securing the DC power cord
4.
Connect the other end of the DC power cord to a DC power
source.
5.
Turn on the power switch on the power module. If the Input LED
is on, the power cord is connected correctly. If the Input LED is
off, the connection might be wrong. Verify the installation and
resolve the problem.
Removing the power module
CAUTION:
To avoid bodily injury and device damage, strictly follow the
procedure in
Figure 8
to remove the power module.
10
