Summary of Contents for H3C SecPath PSR3000-54A

  • Page 1: Table Of Contents

    Contents Overview ·················································· 1     Front panel ···································································· 2   LEDs ············································································ 2   Technical specifications ··················································· 4   Power module configuration ·············································· 4 Installing and removing the power module ······· 6     Installing the power module ··············································· 6  ...

  • Page 2: Overview

    Overview H3C SecPath PSR3000-54A is a AC-input and DC-output power module. It is hot swappable and provides a maximum output of 3000 The power module supports N+1 or N+N redundancy (see "Power module configuration"). It provides a self-protection mechanism against input undervoltage, input overvoltage, output overvoltage, output short circuit, output undercurrent, output overcurrent, and overtemperature conditions.

  • Page 3: Front Panel

    Front panel Figure 1 Front panel (1) Power input LED (AC OK) (2) Handle (3) AC input receptacle (4) Latch (5) Power output LED (DC OK) (6) Air vents (airflow from the inside to outside) LEDs The power module has two LEDs.
  • Page 4 Table 1 LED description Mark Color Description No power input. Low power input voltage. Power AC OK The power module has input LED entered self-protected state. Green Normal power input. Green Normal power output. Abnormal power output (Output short circuit, output overcurrent, output Power overvoltage, output...

  • Page 5: Technical Specifications

    Technical specifications Table 2 Technical specifications Item Specifications Rated input voltage 100 to 240 VAC @ 50 or 60 Hz Rated output voltage 240 VDC Maximum input current 16 A Maximum output current 55.6 A • 1200 W @ 110 VAC •...
  • Page 6 When two mains power inputs are provided, you can configure the power modules in N+N redundancy. N+N must be not greater than the total number of power module slots. When one mains power input is provided, you can configure the power modules in N+1 or N+N redundancy. N+1 or N+N must be not greater than the total number of power module slots.

  • Page 7: Installing And Removing The Power Module

    Installing and removing the power module Installing the power module To avoid bodily injury and device damage, follow the procedures Figure 2 to install the power module. Figure 2 Power module installation procedure Before the installation, prepare an ESD wrist strap yourself.

  • Page 8: Installing The Power Module

    Installing the power module CAUTION: • To install the power module in a slot to the left of the fan tray slots, orient the power module with the latch above the handle. • To install the power module in a slot to the right of the fan tray slots, orient the power module with the latch below the handle.
  • Page 9 Figure 3 Removing the filler panel Unpack the power module. Correctly orient the power module. Holding the power module handle with one hand and supporting the power module bottom with the other, slide the power module along the guide rails into the slot until the latch on the power module clicks into place.

  • Page 10: Connecting The Power Cord

    The power module has a disorientation rejection design. If the power module is oriented incorrectly, you cannot install the power module into the slot. If you encounter a hard resistance while inserting the power module, pull out the power module, reorient it, and then insert it again.

  • Page 11: Removing A Power Module

    The PSR3000-54A power module is provided with a 16 A AC power cord which has a C19 straight entry connector, as shown in Figure You can also use a 16 A AC power cord with a C19 angled connector. To connect the power cord: Plug the AC power cord connector into the AC input receptacle of the power module.

  • Page 12: Removing The Power Cord

    Figure 6 Power module removal procedure Before you remove a power module, prepare an ESD wrist strap yourself. Removing the power cord Turn off the circuit breaker of the power cord. Wear an ESD wrist strap, and make sure the strap makes good skin contact and is correctly grounded.
  • Page 13 WARNING! Allow the power module to cool before you remove the power module. The following procedure removes the power module above the fan tray slots. To remove the power module: Pressing the latch in the direction towards the handle, pull the power module part way out of the slot along the guide rails.
  • Page 14 Install the filler panel in the power module slot.
