The power module and power module slot are designed to
prevent disorientation and misalignment. If you cannot insert the
power module smoothly into the slot, the orientation might be
wrong or the power module is not aligned correctly with the slot.
Pull out the power module, reorient the power module or realign
it with the slot, and insert it again.
4.
When the power module is fully seated in the slot, fasten the
captive screw on the power module.
Figure 4 Installing the power module
1
2
7
