Figure 2 PSR300-12D2
(1) Power switch ("O" represents off and "—" represents on)
(2) Power receptacle
(4) Handle
(6) Power input status LED
(8) Captive screw
(9) Screw holes for securing the power cord connector
LEDs
The power module uses power input and power output LEDs to
indicate the power input and output status, respectively.
(3) Spring tab
(5) Power output status LED
(7) Bail clasp mounting holes
