IBM Power System POWER7 Series Common Service Procedures page 51

Example: Configuration formatting log (unformatted information)
Display Hexadecimal Report for Resource
Name Type
STORAGE 6532
Offset 0 1 2 3 4 5 6 7 8 9 A B C D E F
000180 50407800 65320001 90120210 0FFFFFFF
000190 00000000 00000000 00001400 123C0003
0001A0 00000000 00000000 CA000003 00000000
0001B0 65320001 07050011 00000000 00000000
0001C0 00000000 00000000 47000001 07069205
0001D0 F8F6C7F8 F1F4F9C3 D7D7F8F9 F8F100D5
0001E0 00000000 00000000 00000000 00000000
0001F0 00000000 00000000 00000000 00000000
000200 00000000 00000000 00000000 00000000
000210 00000000 00000000 00000000 00000000
000220 00000000 00000000 00000000 00000000
000230 C3D7D7C5 C1F0F2D5 F6F5F3F2 F9F0F1F2
000240 F0F0F0F0 F0F0F0F0 F0F0F0F0 F0F0C4F4
000250 F0F1F3F4 0000E8D5 00000000 00000000
Figure 18. Example of hexadecimal report, configuration formatting log (unformatted information)
Example: Configuration formatting log template
Display Hexadecimal Report for Resource
Name Type
STORAGE 6532
Offset 0 1 2 3 4 5 6 7 8 9 A B C D E F
000180 -------- -------- -------- --------
000190 -------- -------- -------- ------03
0001A0 -------- -------- -------- --------
0001B0 Current Current Current Current
IOP type IOP
& model serial
0001C0 Expected Expected Expected Expected
IOP type IOP
& model serial
Figure 19. Example of hexadecimal report, configuration formatting log template
Configuration formatting log (as formatted information for type A or B IPL)
Display Additional Information for Resource
Name Type
STORAGE 6532
Configuration . . . . . . :
I/O Processor Information:
Type . . . . . . . . :
Serial Number . . . :
Cache Adaptor Card Information:
Type . . . . . . . . :
Serial Number . . . :
Figure 20. Example of hexadecimal report, configuration formatting log (as formatted information for type A or B IPL)
Serial
Model Number
001 00-50011
EBCDIC
& ..............
................
................
................
..............k.
86G8149CPP8981.N
................
................
................
................
................
CPPEA02N65329012
00000000000000D4
0134..YN........
Serial
Model Number
001 00-50011
Cache Cache
type serial
Cache Cache
type serial
Serial
Model Number
001 00-50011
Current
6532
07050011
0000
00000000
Resource
Name
Resource
Name
Resource
Name
Expected
0000
00000000
4700
07069205
