UM2469
1. Default configuration.
Refer to
information about STMod+ signals available on P1 connector. Refer to
Fanout board
8.4

TAG connector CN9

TAG connector is a 10-pin footprint supporting SWD mode, which shares same signals with
ST-LINK: PA13 (JTMS / SWDIO), PA14 (JTCLK / SWCLK), PB3 (JTDO / SWO), PB4
(NRST).
TC2050-IDC-NL cable is used to link ST-LINK and TAG connector, so users can easily
program and debug the STM32 without using any extra accessory.
Table 9. STMod+: SPI/UART configuration selection (continued)
Pin name
PMOD#3
PMOD#4
STMod+#8
STMod+#9
Section Appendix C: Pmod™ and STMod+ schematic table
to find more information about STMod+ compatible Fanout board.

Figure 16. TAG connector (CN9)

STMod+ SPI STMod+ UART
MISOp
SCK
N/A
N/A
UM2469 Rev 1
STMod+ UART and SPI
RX
RTS
N/A
N/A
to find more
Section Appendix D:
Connectors
(1)
RX
SCK
MOSIs
MISOs
27/59
