Audio Line Output (Green Jack) Connector; Audio Line Input (Blue Jack) Connector; Table 15. Audio Line Output Connector Cn5; Table 16. Audio Line Input Connector Cn4 - ST STM32F7308-DK User Manual

Connectors
8.11.1

Audio line output (green jack) connector

A 3.5 mm stereo audio green jack output CN5 is available to support the headphone (see
Figure 22).
8.11.2

Audio line input (blue jack) connector

A 3.5 mm stereo audio blue jack input CN4 is available to support the audio line input (see
Figure 22).
32/59

Table 15. Audio line output connector CN5

Pin number
3
4
6

Table 16. Audio line input connector CN4

Pin number
3
4
6
UM2469 Rev 1
UM2469
Description
GND
Right
Left
Description
GND
Right
Left
