The following table summarizes the relevant cabling standards:
Category
Follow these recommendations for copper data cabling in high electrical noise envi-
ronments:
•
•
•
1.5.3

Supported Fiber Optic Cables

The following fiber optic cable types are supported under the stated conditions.
Cable Type Wavelength (nm)
OM1 (62.5/125)
OM2 (50/125)
a
OM3 (50/125)
a
OM4 (50/125)
a
Laser optimized.
1.6

Decommissioning and Disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM RSG2488F
Installation Manual, 11/2019, C79000-G8976-1351-05
Cabling 1000Base-
TX Compliant
< 5 No
5 Yes
5e Yes
6 Yes
> 6 Yes
Data cable lengths should be as short as possible, preferably 3 m (10 ft) in
length. Copper data cables should not be used for inter-building communica-
tions.
Power and data cables should not be run in parallel for long distances, and
should be installed in separate conduits. Power and data cables should intersect
at 90° angles when necessary to reduce inductive coupling.
Shielded/screened cabling can be used when required. Care should be taken to
avoid the creation of ground loops with shielded cabling.
Modal Band-
width (MHz·km)
850 200
1300 500
850 500
1300 500
850 1500
1300 500
850 3500
1300 500
Required Action
New wiring infrastructure required.
Verify TIA/EIA-568-A compliance.
No action required. New installations should be designed with Cate-
gory 5e or higher.
No action required.
Connector and wiring standards to be determined.
100Base-FX
—
2000
—
2000
—
2000
—
2000
1.5.3 Supported Fiber Optic Cables
Distance (m)
1000Base-SX
275
—
550
—
550
—
550
—
Introduction
10GBase-SR
33
—
82
—
300
—
400
—
5
