GPIO11 Arduino_IO8
GPIO12 Arduino_IO9
GPIO13 Arduino_IO10
GPIO14 Arduino_IO11
GPIO15 Arduino_IO12
GPIO16 Arduino_IO13
GPIO17
GPIO18
GPIO19
GPIO20
GPIO21
GPIO22 HEX2_D0
GPIO23 HEX2_D1
GPIO24 HEX2_D2
GPIO25 HEX2_D3
GPIO26 HEX2_D4
GPIO27 HEX2_D5
GPIO28 HEX2_D6
GPIO29 HEX3_D0
GPIO30 HEX3_D1
GPIO31 HEX3_D2
GPIO32 HEX3_D3
GPIO33 HEX3_D4
GPIO34 HEX3_D5
GPIO35 HEX3_D6
 Arduino Uno Expansion Header
The board provides Arduino Uno revision 2 compatibility expansion header which comes with four
independent headers. The headers connect serial resistor 47 ohm to 15 pins (14pins GPIO and 1pin
Reset) of the Cyclone V GX FPGA, 8-pins Analog input connects to ADC, and also provides DC
+12V (VCC12), DC +5V (VCC5), DC +3.3V (VCC3P3), and three GND pins.
Please refer to Figure
the signal name (shared bus) connected to FPGA.
GPIO DATA[11] , Arduino IO8
GPIO DATA[12] , Arduino IO9
GPIO DATA[13] , Arduino IO10
GPIO DATA[14] , Arduino IO11
GPIO DATA[15] , Arduino IO12
GPIO DATA[16] , Arduino IO13,
PLL Clock output
GPIO DATA[17]
GPIO DATA[18] , PLL Clock output
GPIO DATA[19]
GPIO DATA[20]
GPIO DATA[21]
GPIO DATA[22]
GPIO DATA[23]
GPIO DATA[24]
GPIO DATA[25]
GPIO DATA[26]
GPIO DATA[27]
GPIO DATA[28]
GPIO DATA[29]
GPIO DATA[30]
GPIO DATA[31]
GPIO DATA[32]
GPIO DATA[33]
GPIO DATA[34]
GPIO DATA[35]
3-27. for detailed pin-out information. The red font in
52
3.3-V PIN_U22
3.3-V PIN_P8
3.3-V PIN_R8
3.3-V PIN_R9
3.3-V PIN_R10
3.3-V PIN_F26
3.3-V PIN_Y9
3.3-V PIN_G26
3.3-V PIN_Y8
3.3-V PIN_AA7
3.3-V PIN_AA6
3.3-V PIN_AD7
3.3-V PIN_AD6
3.3-V PIN_U20
3.3-V PIN_V22
3.3-V PIN_V20
3.3-V PIN_W21
3.3-V PIN_W20
3.3-V PIN_Y24
3.3-V PIN_Y23
3.3-V PIN_AA23
3.3-V PIN_AA22
3.3-V PIN_AC24
3.3-V PIN_AC23
3.3-V PIN_AC22
Figure 3-28 represents
