SIMATIC
Industrial PC
SIMATIC IPC1047
Operating Instructions
09/2018
A5E45118479-AA
___________________
Preface
___________________
Overview
___________________
Safety Instructions
___________________
Installing and connecting the
device
___________________
Commissioning the device
___________________
Extended device functions
___________________
Expanding and assigning
parameters to the device
___________________
Device maintenance and
repair
___________________
Technical specifications
___________________
Technical support
___________________
Abbreviations
1
2
3
4
5
6
7
8
A
B

Advertisement

Table of Contents
loading

Related Manuals for Siemens SIMATIC IPC1047

Summary of Contents for Siemens SIMATIC IPC1047

  • Page 1 ___________________ Preface ___________________ Overview ___________________ SIMATIC Safety Instructions ___________________ Installing and connecting the device Industrial PC SIMATIC IPC1047 ___________________ Commissioning the device ___________________ Extended device functions Operating Instructions ___________________ Expanding and assigning parameters to the device ___________________ Device maintenance and...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Preface

    A solid background in personal computers and Microsoft operating systems is required to understand this manual. Validity of the Operating Instructions These operating instructions are valid for all supplied versions of the SIMATIC IPC1047. Scope of this documentation The documentation for the SIMATIC IPC1047 includes: ●...
  • Page 4 Preface SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 5: Table Of Contents

    Automatic switching on of the device ................. 41 Notes on different device configurations ................41 4.4.1 Opening the front door ....................... 41 4.4.2 Multi-disk system ....................... 41 4.4.3 RAID systems ........................42 4.4.3.1 Manage RAID system ......................42 SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 6 Special feature: Replacing hard disk in the RAID system when switched off......79 7.3.6 Integrating a new hard disk drive in the RAID system ............79 Managing the Hardware RAID system ................82 7.4.1 Calling Adaptec maxView Storage Manager ...............82 SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 7 IPMI Setup ........................114 Technical support ........................115 Troubleshooting ......................115 RAID system and device startup ..................117 Notes on the use of third-party modules ................118 Abbreviations ..........................119 Glossary ........................... 125 Index ............................133 SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 8 Table of contents SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 9: Overview

    Overview Product description 1.1.1 Overview The SIMATIC IPC1047 is a high-performance rack PC with industrial functionality: ● Highly compact ● Extremely rugged ● Extensive product continuity 1.1.2 Expansion stages/device variants Several variants of the device are available: ● CPU Performance, article number 6BK1800-1HA01-0AA0: Device variant with high CPU performance for compute-intensive applications.

  • Page 10: Scope Of Application

    It has a high degree of flexible expandability for diverse performance-driven applications: ● Scientific calculations and simulations ● Image processing and editing ● Cryptography ● Process monitoring ● Virtualization ● Quality assurance ● Scada applications ● Artificial intelligence, machine learning SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 11: Highlights

    – "Zero-Maintenance Cache Protection" protects the data in the hardware RAID controller cache in the event of a power failure – Reduced load on the main processor during the rebuild – Fast HDDs/SSDs for high speed when reading and writing data SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 12: Features

    POWER (internal power supply present, PC switched on) • HDD (access to hard disk) • FAN FAIL (display fan problems) • Power supply status, power, Monitoring of redundant power supply (optional) temperatures, voltages SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 13 For a maximum of 8 SAS drives – High-performance Operating system Windows Server 2012 R2 • Power supply, redundant 100 … 240 V AC wide-range, 10-5 A, 60-50 Hz, 700 Watt Compatibility with the motherboard (http://www.supermicro.com.tw/support/resources/OS/C612_X10_list2.cfm) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 14: Design Of The Device

    Rear view with AC power supply ① ATX power supply ② Indicator light ③ On/off switch ④ Power supply connection ⑤ Interfaces ⑥ Expansion card slots ⑦ PCI expansion kit interface (optional) ⑧ 2nd COM interface (optional) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 15: Interfaces

    2nd COM interface (optional) 1.2.2 Interfaces ① COM interface ② RJ45 IPMI dedicated LAN connection ③ USB 2.0 ports ④ USB 3.0 ports ⑤ Gbit ETHERNET interface 1 ⑥ Gbit ETHERNET interface 2 ⑦ VGA connection SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 16: Status Displays

    Access to hard disk No access GREEN Access ③ FAN FAIL Fan status No error RED flashing Possible causes: CPU heat sink fan fault • Front fan faulty • Power supply fan fault • SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 17 Data transmission rate 10 Mbps • GREEN 100 Mbps • YELLOW 1000 Mbps • The Ethernet ports are numbered on the enclosure to identify them clearly. The numbering by the operating system may deviate from this. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 18: Power Indicators, Redundant Power Supply

    GREEN Power supply module 2 in operation • PC switched on • Flashes RED Power supply 2 interrupted Power supply module 2 defective Flashes slowly Warning at power supply module 2, e.g. RED/GREEN overload SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 19: Safety Instructions

    • Always fully disconnect the device from the mains voltage before performing work on the device or when the device will not be used over an extended period of time. • For control cabinet mounting: If possible, use a central, easily accessible power disconnector near the unit. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 20 Electrostatic sensitive devices (ESD) The device contains electronic components that may be destroyed by electrostatic charges. This can result in malfunctions and damage to the machine or plant. Take corresponding precautionary measures before you open the device. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 21 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply latest updates may increase customer’s exposure to...
  • Page 22 A damaged device has unpredictable properties and states. Death or serious injury could occur. • Avoid installing and commissioning a damaged device. • Label the damaged device and keep it locked away. Send off the device for immediate repair. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 23 • Circuit overload When connecting the devices to the power supply, observe the rated values specified on the nameplate of the devices. • Reliable grounding Reliable grounding of rack-mounted equipment should be ensured. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 24 Excessive sound pressure from headphones can result in impaired hearing or even loss of hearing. Set the volume control and equalizer to the lowest value before you put on the headphones. Keep checking the volume control setting. Only use headphones and software approved by the manufacturer. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 25: Notes On Use

    ● UL approval of the device only applies when the UL-approved components are used according to their "Conditions of Acceptability". ● We are not liable for functional limitations caused by the use of third-party devices or components. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 26 • The affected IPC must be switched off and the power plug must be plugged in. • All cables from the system must be connected to the IPC during measurement. • All other components in the plant must be active. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 27: Installing And Connecting The Device

    The data can be found on the front of the device when the front door is open. ● Serial number (S): The serial number can be found on the nameplate (figure as an example): ● Order number of the device SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 28: Checking The Delivery Package

    • Keep the original packaging. • Pack the device in the original packaging for transportation and storage. 5. Check the contents of the packaging and any accessories you may have ordered for completeness and damage. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 29 7. Please keep the enclosed documentation in a safe place. It belongs to the device. You need the documentation when you commission the device for the first time. 8. Write down the identification data of the device. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 30: Permitted Mounting Positions

    Before you install the device, note the following general installation information. Note The device meets the requirements for fire protection enclosures in accordance with EN 60950-1. It can therefore be installed without an additional fire protection enclosure. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 31: Mounting Instructions

    The device may fall down, injure people and get damaged. Secure the device using additional measures. The mounting screws of the telescopic rails may not protrude more than 5 mm into the device. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 32 The telescopic rails are secured with M4 screws. The dimensions for the mounting holes are listed in the chapter "Dimension drawing for telescope rails (Page 106)". Position of the mounting holes for angle brackets The mounting holes for the angle brackets are highlighted in the following figure. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 33: Connecting The Device

    The device is designed for use on a grounded power supply grid (TN networks per VDE 0100 Part 100 or IEC 60364-1). Operation with non-grounded or impedance-grounded networks (IT networks) is not permitted. Rated voltage The permitted rated voltage must match the local line voltage. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 34: Connecting Peripheral Equipment

    Hot-plug I/O devices (USB) may be connected while the PC is in operation. NOTICE Non-hot-plug I/O devices I/O devices that do not support hot-plugging may not be connected until the device is powered off. Strictly adhere to the specifications in the I/O manuals. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 35 • The computer in question must be turned off and the power supply connector must be plugged in. • During the measurement, all cables from the plant to the computer should be connected. • All other components in the plant must be active. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 36: Connecting The Power Supply

    15 A / 250 V ground contact connector. The cable set must be compliant with the safety regulations of the country where the device is to be installed and carry the identification labels required by law. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 37 3. Plug the power cable plug into the power outlet. ① 4. Set the on/off switch to position 'I'. The power LED to the left of the on/off switch and on the front panel of the device lights SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 38: Connecting A Redundant Power Supply

    Note If only one power supply module is switched on or connected, or a module is defective, a warning signal is emitted. The warning signal stops when the acknowledgment key is pressed. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 39: Commissioning The Device

    ● An operating system is installed. The device can be supplied without an operating system. You can find additional information on installation of the operating system in the section "Installing the software (Page 90)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 40: Switching On The Device

    The product key is located on the "Certificate of Authentication" in the "Product Key" line, see section "Identification data of the device (Page 27)". Result The interface of the operating system is displayed every time you turn on the device and after the startup routine. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 41: Automatic Switching On Of The Device

    Booting from the second hard disk drive In order to allow booting from the second hard disk drive, you need to configure it as the primary boot device (Boot Option #1). Make the following settings in your BIOS setup: SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 42: Raid Systems

    The safe system states RAID Level, for example, 1 are only reached once synchronization has been successfully completed. In addition, system performance may be limited in the case of a manually started maintenance operation until completion of the maintenance phase. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 43: Raid System Of The Motherboard

    ● For applications with stringent requirements regarding low system disturbances of the RAID system. ● With maintenance-free battery backup for high data reliability. ● The RAID controller with PCIe x8 interface occupies one PCIe x8 or x16 expansion slot of the device. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 44 The 4-port or 8-port variant can be used. An optionally available hot-spare drive can further increase the availability of the system. ① Connection for the SAS/SATA data cable ② Connection for Zero Maintenance Module (ZMM) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 45 In order to use the software, the operating system must be password-protected. The password must be assigned before the software is installed. In a correct installation, the operating system password and RAID software password are the same. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 46: Raid1 System

    For non-Windows operating systems: ● Briefly press the on/off button. The operating system is shut down. The "POWER" LED goes out. The device is switched off but not fully disconnected from the line voltage. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 47 Perform a hardware reset only in the case of an emergency. 1. Press the on/off switch for more than 4 seconds. 2. Alternatively, press the reset button. Information on the position of the buttons is available in the section "Device views (Page 14)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 48 Commissioning the device 4.6 Switching off the device SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 49: Extended Device Functions

    Among the functions provided by IPMIView are the following: ● Configuration management with IP address assignment ● Firmware update ● Access protection with user and PC group management ● Password assignment and login SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 50: Trusted Platform Module (Tpm)

    The warranty does not cover a reset of the hardware in the event of a loss of a password. Please store the password carefully and make sure it is protected against unauthorized access. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 51: Expanding And Assigning Parameters To The Device

    Basic configuration without expansion cards Temperature range 0 °C to 40 °C (maximum configuration) Expansion up to 6 expansion cards: The maximum power loss of all expansion cards is 650 W. Maximum permitted configuration SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 52: Opening The Front Door

    The device contains electronic components that may be destroyed by electrostatic charges. This could result in damage to the device and affect the machine and plant. • Take suitable precautionary measures before you open the device. • Read section "ESD guideline (Page 103)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 53 Disclaimer of liability All technical specifications and approvals apply only to expansions which are approved by the Siemens AG. We are not liable for functional limitations caused by the use of third-party devices or components. Observe the installation instructions for the components. UL approval of the device only applies when UL-approved components are used according to their "Conditions of...

  • Page 54: Drives

    ● Tray 2: 2 × 2.5" drives, horizontal format ● Tray 1: 1 × 2.5" drive, vertical format Additional mounting location: An additional hard disk drive can be installed between the top mounting location and the enclosure wall. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 55 ● 2 × 2.5" ● 2 × 2.5" ● 2 × 2.5" ● 2 × 2.5" Mixed installation: ● 1 × 3.5" ● 1 × 3.5" ● 1 × 2.5" ● 1 × 2.5" SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 56: Removing And Installing A Tray From/In The Drive Cage

    Removing and installing 3.5" drives from/in tray Requirement ● The tray has been removed, see section "Removing and installing a tray from/in the drive cage (Page 56)". ● 1 drive ● 1 soft mounting base SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 57: Removing And Installing 2.5" Drives From/In Tray

    Removing and installing 2.5" drives from/in tray Requirement ● The tray has been removed, see section "Removing and installing a tray from/in the drive cage (Page 56)". ● 1 drive ● 1 soft mounting base SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 58 Ensure that each hole of the tray is positioned exactly over the threads of the drive. 4. Screw on the drive from behind. Do not tighten the screws too much. Do not exceed the maximum tightening torque of 0.7 Nm. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 59 Expanding and assigning parameters to the device 6.4 Drives Installation in vertical format Installation in horizontal format SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 60: Replacing A Defective Hard Disk Drive In The Raid System

    An internal hard disk drive may only be replaced when the device is switched off. The new hard disk drive can be integrated into the RAID1 system at operating system level with the RAID software. Synchronization may take several hours, depending on system load. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 61: Expansion Cards

    • Do not use a fanless graphics card and a self-venting graphics card at the same time. Only use graphics cards with the same fan type: only fanless graphics cards or only self- venting graphics cards. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 62: Removing And Installing Expansion Cards

    3. Secure the expansion card with the corresponding screw. Removal Proceed in the reverse order for the removal. In step 2, unlock the expansion card in the slot before removing it. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 63: Installing The Pci Expansion Kit (Optional)

    6.5.3 Installing the PCI expansion kit (optional) Requirement The PCI expansion kit consists of the following components: ● Card retainer ● Fixing pins and screws ● Riser card with slot for PCI expansion card SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 64 5. Press the outside of the guide rail bracket against the locking element and screw it in place, as shown. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 65: Remove And Install Fanless Graphics Card (Optional)

    2. NOTICE: Do not interchange the SATA connectors during installation: Make a note of which SATA connector is connected to which slot. Detach the SATA cables below the fan. 3. Unhook the fan in the downward direction. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 66 Do not interchange the SATA cables during installation. Note the assignment of the SATA cables to their slots in step 2. Damaged cables When hooking in the fan in step 3, ensure that no SATA or fan cables are caught in between. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 67: Removing And Installing The Self-Ventilating Graphics Card

    There is a risk of injury at the rotating parts of the fan, e.g. through cutting. • Wait until the fan blades come to a standstill. • Only then should you remove the graphics card. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 68 4. Release the locking mechanism on the socket, remove the ④ graphics card together with ⑥ the support adapter place it carefully on the mounting base. The modules face down. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 69: Installing And Configuring The Hardware Raid Adapter Card

    For installation of the Hardware RAID adapter card, you require the following: ● Tx10 screwdriver ① ● The hardware RAID adapter card with connection for the SAS/SATA data cable ② connection for the capacitor block of the ZMM SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 70 When setting up the Hardware RAID system, set the write cache of the RAID controller as follows (see the additional documentation of Adaptec): • Write Caching - Enable with Backup Unit • create RAID via: Build/Verify SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 71 • "Drives Write Cache = Disabled", which means the write cache of the hard disk is switched off. • "Alarm Control = Disabled", which means the acoustic alarm in case of a fault is switched off SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 72: Install The Com Port (Optional)

    3. Insert the slot bracket with the pin connector of the COM interface and screw it in place. 4. Insert the plug connector onto the marked location on the motherboard. No other steps are needed for installing the COM interface. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 73: Device Maintenance And Repair

    UL approval of the device only applies when the UL-approved components are used according to their "Conditions of Acceptability". We are not liable for functional limitations caused by the use of third-party devices or components. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 74: Maintenance

    1 year or earlier depending on the degree of soiling Device fan 6BK1700-6HA71-0AA0 3 years Backup battery 6BK1700-6HA73-0AA0 5 years Windows 7 A5E45470904 Professional SP1 x64 Restore USB stick Windows Server 2012 R2 A5E45471221 Recovery USB stick SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 75: Remove The Fan Cover

    2. Insert the new filter pad into the fan cover. It is inserted loosely in the fan cover. When you insert the filter pad, make sure it lies evenly in the fan cover. 3. Replace the fan cover. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 76: Manage Onboard Raid System

    "UEFI Boot Type in the "Boot" menu in the BIOS setup, the RAID hardware is configured by using the "Device Management" button in the BIOS selection menu. 7.3.1 Example for a RAID1 system during the boot phase of the system SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 77: Raid Software

    It may take a very long time (hours or even days in the case of a high drive load) to synchronize a new hard disk in the background, depending on its size and on the system load. The redundant system state is reached again only after synchronization is completed. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 78: Displaying A Defective Hard Disk Of A Raid System In The Raid Software

    You can find information on how to detect and replace a defective hard disk in the RAID system in the section "Replacing a defective hard disk drive in the RAID system (Page 60)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 79: Special Feature: Replacing Hard Disk In The Raid System When Switched Off

    ● The hard disk to be integrated is brand new or is set up as a spare drive. Notes on creating spare drives are available in the controller documentation. Sequence The following figure is an example for the automatic rebuilding process. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 80 "Run Hardware Scan now". The new hard disk is found and displayed. 1. Reboot the device. The RAID software automatically integrates the hard disk. 2. Click the "Rebuild to another Disk" link. The RAID system is synchronized. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 81 The new hard disk is then assigned to a SATA port and is integrated into the RAID system. A defective hard disk is still displayed during the rebuilding process. This display disappears when the rebuilding process is completed. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 82: Managing The Hardware Raid System

    Internet Explorer Enhanced Security Configuration. https://127.0.0.1" You can find step-by-step instructions on installing the certificate and setting up the trusted sites on the Internet at the following address: Details: Instructions for calling the Adaptec maxView Storage Manager (http://support.automation.siemens.com/WW/view/en/102295361) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 83: Removing And Installing Hardware

    "Switching off the device (Page 46)". ● The device is open; see section "Open the device. (Page 52)". ● 1 fan; for article numbers, see section "Maintenance" Procedure Read section "ESD guideline (Page 103)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 84 1. Detach the plug of the connecting cable of the fan from the motherboard. 2. Detach the protective grille from device fan. 3. Lift the device fan in the marked keyhole and remove it towards the front. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 85: Replacing The Backup Battery

    Conductive materials cause a battery short-circuit or damage adjacent modules. • Only use insulated materials as tools for the battery replacement. • Do not touch any adjacent modules. • Read section "ESD guideline (Page 103)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 86 ● Set the BIOS setup. The configuration data of the device may be deleted after a battery replacement depending on the BIOS setup setting. See also Remove and install fanless graphics card (optional) (Page 65) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 87: Replacing The Redundant Power Supply Module

    • The replacement of one of the two modules of the redundant power supply can be performed, however, without shutting down the device. Requirement ● The power supply lines are connected, see section "Connecting a redundant power supply (Page 38)" Procedure Read the section "ESD guideline (Page 103)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 88: Replacing The Processor

    If the processor type is changed, the BIOS must be updated so that the suitable microcode is loaded. Information about original spare parts for SIMATIC IPCs is available on the Internet at: – Contacts (http://www.siemens.com/automation/partner) – SIMATIC IPC after-sales information system (http://www.siemens.com/asis) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 89 The processor is not correctly locked in place by the bay. The result may be malfunctions. • Do not use excessive force. • Tilt the lever back again and try again. 8. Place the heat sink back on the processor and tighten the screws. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 90: Installing The Software

    Restoring the factory settings of the operating system and partitions (Restore) The Restore function restores the factory settings of the device (which means the volume partitions, the operating system with installed device drivers, and the SIEMENS software products) (however, see section "Back-up authorization or license key (Page 90)").
  • Page 91 The firmware settings might have to be changed in order for the device to boot from the provided USB stick. NOTICE Risk of data loss Files, user settings as well as existing authorizations and license keys are lost when a restore is performed! • Back up your data before restoring. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 92: Updating The Operating System

    3. Boot with the provided USB stick in the Boot mode you have set beforehand. 4. In the Windows® Boot Manager, select the option "Restore Microsoft Windows ..." and confirm the selection. The Restore program from Siemens starts after a few seconds. 5. Follow the instructions on the screen. Note the following information.

  • Page 93: Installing Windows (Recovery)

    7.6.5 Installing Windows (Recovery) The recovery function only installs the operating system on your device. In contrast to the restore function, no device drivers and no SIEMENS software products are installed by the recovery function. Note Specific information on using the Windows operating systems is available on the Internet: •...
  • Page 94 4. In the Windows Boot Manager, select the "Recovery Microsoft Windows ..." option and confirm the selection. The Windows installer starts after a few seconds. 5. Follow the instructions on the screen. Note the following information. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 95 Please read the information in the section "Information for systems with RAID or AHCI controller". Drive options Display of additional functions that you can use to set up the data storage media, (advanced) see the following figure. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 96 RAM you have available and how much additional software you want to use. Information on how the data medium is partitioned in its factory state is available in the tables below. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 97 1. Connect the USB stick with the controller driver to the device. 2. Start the "Install Windows" installation program as described above. 3. Select "Load Drivers" in the Windows installation window. 4. Select the respective driver on the USB stick. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 98: Setting Up The Language Selection Using The Multilanguage User Interface (Mui)

    Windows Server 2012 R2: 1. Choose: "Start > Control Panel > Clock, Language and Region > Region" 2. You can make the required changes in the "Administrative" tab. You copy the settings by clicking the respective button. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 99: Installing Hardware Raid Controller Software

    Dism /online /Add-Package /PackagePath:E:\Languagepacks\ja-jp\lp.cab 7.6.7 Installing Hardware RAID controller software Note Observe the "General information on commissioning (Page 39)" in section "Commissioning the device". Additional information is available in section "Installing drivers and software (Page 92)". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 100: Recycling And Disposal

    ● Do not dispose the device or its replacement and expansion components in household waste and not at public waste disposal points. ● For environmentally compatible recycling and disposal of the device and its components, contact a certified disposal company for electronic waste or your Siemens contact (product return (https://support.industry.siemens.com/cs/ww/en/view/109479891)). Observe the following: ●...

  • Page 101: Technical Specifications

    Only the approvals printed on the rating plate apply to the device. ISO 9001 certificate The Siemens quality management system for our entire product creation process (development, production and sales) meets the requirements of ISO 9001. This has been certified by DQS (the German society for the certification of quality management systems).

  • Page 102: Directives And Declarations

    1:2005 +A1+A2. WEEE Directive The device is low-emission, recyclable and meets the requirements of the WEEE Directive 2012/19/EU on the disposal of waste electrical and electronic equipment. Siemens AG is registered with Stiftung EAR, WEEE-Reg. No. DE 23691322. SIMATIC IPC1047...

  • Page 103: Esd Guideline

    The material with which this person comes into contact is of particular significance. The figure shows the maximum electrostatic voltages with which a person is charged, depending on humidity and material. These values conform to the specifications of IEC 61000-4-2. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 104 This way, the discharge energy does not reach and damage the sensitive components. – Discharge your body electrostatically before you take a measurement at a module. Do so by touching grounded metallic parts. Always use grounded measuring instruments. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 105: Dimension Drawings

    Technical specifications 8.3 Dimension drawings Dimension drawings 8.3.1 Dimensional drawing of the device All dimensions in mm SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 106: Dimension Drawing For Telescope Rails

    PCIe Example PCIe: Graphics card nVIDIA TESLA 106.68 mm / 4.2" 111.15 mm / 4.38" 110 mm 312 mm / 12.28" 265 mm Single Slot Dual Slot: The card requires two free expansion slots SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 107: Technical Specifications

    Filter class G2 EN 779, 99% of particles > 0.5 mm are filtered Safety Protection class Protection class I according to IEC 61140 Safety regulations IEC 60950-1 • EN 60950-1 • UL 60950-1 • CSA C22.2 No 60950-1-07 • SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 108 Tested according to DIN IEC 60950-1 During operation 1080 … 689 hPa, corresponds to an elevation of –1000 to 3000 m Storage/transport 1080 … 660 hPa, corresponds to an elevation of -1000 to 3500 m SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 109 Up to 1024 SAS and SATA drives • 8 Lanes PCIe 3.0 • Supported RAID level: 0, 1, 1E, 10 • Supports SSD, HDD, tape drives • Software RAID Supported RAID level: 0, 1, 5, 10 • SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 110: Current And Power Requirements

    (120 VAC) Specified in A Depends on the selected device configuration Observe the maximum permissible values for the total power of the voltages (see next section) Lower permissible total power with redundant power supply SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 111: Power Supply (Ac)

    The total current consumption of the +5 V and + 3.3 V voltage must not exceed 40 A. Power Good Signal preset time: 100 - 500 ms hold-up time: 15 ms minimum save time: 1 ms minimum SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 112: Ac Power Supply, Redundant

    SIMATIC PCs with an active PFC. UPS characteristics are described and classified in the standards EN 50091-3 and IEC 62040-3. Devices with sinusoidal output voltage in the normal and buffered mode are identified with the classification "VFI-SS-.." or "VI-SS-..". SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 113: Hardware Description

    Note Documentation You can find the BIOS description from the manufacturer at Supermicro (https://www.supermicro.com/products/motherboard/xeon/c600/x10dri.cfm) SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 114: Ipmi Setup

    1. Set up the dynamic address assignment via DHCP Alternatively, assign a fixed IP address, e.g. "192.168.10.253". 2. Establish a connection to IPMIView (see section "Monitoring functions (Page 49)"). 3. Set up the remote control via iKVM (also IPMIView). SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 115: Technical Support

    If you use an adapter or extension for the mouse • cable, also check these connectors. If the mouse pointer still does not appear on the screen after you have performed these checks and actions, contact your technical support team. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 116 One module is not switched on Switch on both modules • • despite redundant Connect modules to separate AC circuits Both modules are connected • • power supply in so the same AC circuit case of power failure SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 117: Raid System And Device Startup

    BIOS Activate UEFI boot in the BIOS setup. • setup The boot data carrier is • set up with GPT and UEFI boot is deactivated in the BIOS setup SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 118: Notes On The Use Of Third-Party Modules

    PC. If the error no longer occurs, the Signal frequencies or signal • third-party expansion card was the cause of the fault. levels are not adhered to Replace this expansion card with a Siemens card or contact Different connector pin • the card supplier. assignments If the PC still crashes, contact your technical support team.

  • Page 119: Abbreviations

    Cathode Ray Tube Canadian Standards Association Canadian organization for tests and certifications according to own or binational standards (with UL / USA) standards Clear To Send Clear to send DRAM Dynamic Random Access Memory SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 120 Full name of a domain Front Side Bus Ground Chassis ground Globally Unique Identifier Partition Table Hard disk Hard disk High Definition Audio Hard Disk Drive Hard disk drive Height unit Human Machine Interface User interface SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 121 Multilanguage User Interface Language localization in Windows Not Applicable NAMUR Normenarbeitsgemeinschaft for Mess- und Regelungstechnik in der chemischen Industrie (standardization body for instrumentation and control technology in the chemicals industry) Not Connected Not connected SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 122 Memory cells in which only one bit per cell is saved SMART Self Monitoring Analysis and Reporting Hard disk error diagnostics program Technology Short Message Service Short message via telecommunication network SNMP Simple Network Management Protocol Network protocol SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 123 Wake on Local Area Network World Wide Web Extended Disable Capability Hardware implementation Extended Graphics Array Graphic standard, maximum resolution 1024x768 pixels. Zero Maintenance Cache Protection Module Maintenance-free cache unit for saving cache contents SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 124 Abbreviations SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...

  • Page 125: Glossary

    Communauté Européene. The CE symbol confirms the conformity of the product with all applicable EC directives such as the EMC Directive. Chipset Located on the motherboard, connects the processor with the RAM, the graphics controller, the PCI bus, and the external interfaces. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 126 RAM modules with and without ECC. EMC directive EU directive for electromagnetic compatibility. Compliance is confirmed by the CE symbol and the EC certificate of conformity. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 127 Formatting Basic partitioning of memory space on a magnetic data medium into tracks and sectors. Formatting deletes all data on a data medium. All data media must be formatted prior to their first use. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
  • Page 128 The devices connected to a LAN are called nodes. The purpose of networks is the mutual use of files, printers or other resources. SIMATIC IPC1047 Operating Instructions, 09/2018, A5E45118479-AA...
