2.3. Drive model numbers – IP55
Mechanical dimensions and mounting information are shown from section 3.4.2 on page 122.
Electrical specifications are shown in section 10.2 on page 47.
kW Model Number
ODP‐2‐42055‐3KF4N‐SN
ODP‐2‐42075‐3KF4N‐SN
ODP‐2‐42110‐3KF4N‐SN
ODP‐2‐52150‐3KF4N‐SN
ODP‐2‐52185‐3KF4N‐SN
ODP‐2‐62022‐3KF4N‐SN
ODP‐2‐62030‐3KF4N‐SN
ODP‐2‐62037‐3KF4N‐SN
ODP‐2‐62045‐3KF4N‐SN
ODP‐2‐72055‐3KF4N‐SN
ODP‐2‐72075‐3KF4N‐SN
kW Model Number
ODP‐2‐44110‐3KF4N‐SN
ODP‐2‐44150‐3KF4N‐SN
ODP‐2‐44185‐3KF4N‐SN
ODP‐2‐44220‐3KF4N‐SN
ODP‐2‐54300‐3KF4N‐SN
ODP‐2‐54370‐3KF4N‐SN
ODP‐2‐64045‐3KF4N‐SN
ODP‐2‐64055‐3KF4N‐SN
ODP‐2‐64075‐3KF4N‐SN
ODP‐2‐64090‐3KF4N‐SN
ODP‐2‐74110‐3KF4N‐SN
ODP‐2‐74132‐3KF4N‐SN
ODP‐2‐74160‐3KF4N‐SN
kW Model Number
ODP‐2‐75132‐3K04N‐SN
ODP‐2‐75150‐3K04N‐SN
ODP‐2‐75185‐3K04N‐SN
ODP‐2‐75200‐3K04N‐SN
kW Model Number
ODP‐2‐46185‐3KF0N‐SN
ODP‐2‐46220‐3KF0N‐SN
ODP‐2‐56300‐3KF0N‐SN
ODP‐2‐56370‐3KF0N‐SN
ODP‐2‐56450‐3KF0N‐SN
ODP‐2‐66055‐3KF0N‐SN
ODP‐2‐66075‐3KF0N‐SN
ODP‐2‐66090‐3KF0N‐SN
*Note : The final two characters of the model number relate to available factory build options as follows
‐SN Standard Seven Segment LED Display, standard PCB coating
‐SC Standard Seven Segment LED Display, additional PCB conformal coating
‐TN OLED Text Display Display, standard PCB coating
‐TC OLED Text Display, additional PCB conformal coating
Optidrive ODP‐2 User Guide Revision 1.30
200‐240V ±10% ‐ 3 Phase Input
kW HP Model Number
*
5.5 ODP‐2‐42075‐3HF4N‐SN
*
7.5 ODP‐2‐42100‐3HF4N‐SN
*
11 ODP‐2‐42150‐3HF4N‐SN
*
15 ODP‐2‐52020‐3HF4N‐SN
*
18.5 ODP‐2‐52025‐3HF4N‐SN
*
22 ODP‐2‐62030‐3HF4N‐SN
*
30 ODP‐2‐62040‐3HF4N‐SN
*
37 ODP‐2‐62050‐3HF4N‐SN
*
45 ODP‐2‐62060‐3HF4N‐SN
*
55 ODP‐2‐72075‐3HF4N‐SN
*
75 ODP‐2‐72100‐3HF4N‐SN
380‐480V ±10% ‐ 3 Phase Input
kW HP Model Number
*
11 ODP‐2‐44150‐3HF4N‐SN
*
15 ODP‐2‐44200‐3HF4N‐SN
*
18.5 ODP‐2‐44250‐3HF4N‐SN
*
22 ODP‐2‐44300‐3HF4N‐SN
*
30 ODP‐2‐54040‐3HF4N‐SN
*
37 ODP‐2‐54050‐3HF4N‐SN
*
45 ODP‐2‐64060‐3HF4N‐SN
*
55 ODP‐2‐64075‐3HF4N‐SN
*
75 ODP‐2‐64120‐3HF4N‐SN
*
90 ODP‐2‐64150‐3HF4N‐SN
*
110 ODP‐2‐74175‐3HF4N‐SN
*
132 ODP‐2‐74200‐3HF4N‐SN
*
160 ODP‐2‐74250‐3HF4N‐SN
480‐525V ±10% ‐ 3 Phase Input
kW HP Model Number
*
132
*
150
*
185
*
200
500‐600V ±10% ‐ 3 Phase Input
kW HP Model Number
*
18.5 ODP‐2‐46250‐3HF0N‐SN
*
22 ODP‐2‐46300‐3HF0N‐SN
*
30 ODP‐2‐56400‐3HF0N‐SN
*
37 ODP‐2‐56050‐3HF0N‐SN
*
45 ODP‐2‐56060‐3HF0N‐SN
*
55 ODP‐2‐66075‐3HF0N‐SN
*
75 ODP‐2‐66100‐3HF0N‐SN
*
90 ODP‐2‐66125‐3HF0N‐SN
www.invertekdrives.com
HP Output Current (A)
*
7.5 24
*
10 39
*
15 46
*
20 61
*
25 72
*
30 90
*
40 110
*
50 150
*
60 180
*
75 202
*
100 248
HP Output Current (A)
*
15 24
*
20 30
*
25 39
*
30 46
*
40 61
*
50 72
*
60 90
*
75 110
*
120 150
*
150 180
*
175 202
*
200 240
*
250 302
HP Output Current (A)
185
205
255
275
HP Output Current (A)
*
25 28
*
30 34
*
40 43
*
50 54
*
60 65
*
75 78
*
100 105
*
125 130
Frame Size
4
4
4
5
5
6
6
6
6
7
7
Frame Size
4
4
4
4
5
5
6
6
6
6
7
7
7
Frame Size
7
7
7
7
Frame Size
4
4
5
5
5
6
6
6
9
