Par
Description
P0‐31 Drive Lifetime Operating Time
Displays the total operating time of the drive. The first value shown is the number of hours. Pressing the Up key will display the
minutes and seconds.
P0‐32 Drive Run Time Since Last Trip (1)
Displays the total operating time of the drive since the last fault occurred. The first value shown is the number of hours. Pressing
the Up key will display the minutes and seconds.
P0‐33 Drive Run time Since Last Trip (2)
Displays the total operating time of the drive since the last fault occurred. The first value shown is the number of hours. Pressing
the Up key will display the minutes and seconds.
P0‐34 Drive Run Time Since Last Disable
Displays the total operating time of the drive since the last Run command was received. The first value shown is the number of
hours. Pressing the Up key will display the minutes and seconds.
P0‐35 Drive Internal Cooling Fan Total Operating Time
Displays the total operating time of the Optidrive internal cooling fans. The first value shown is the number of hours. Pressing
the Up key will display the minutes and seconds. This is used for scheduled maintenance information
P0‐36 DC Bus Voltage Log (256ms)
P0‐37 DC Bus Voltage Ripple Log (20ms)
P0‐38 Heatsink Temperature Log (30s)
P0‐39 Ambient Temperature Log (30s)
P0‐40 Motor Current Log (256ms)
The above parameters are used to store the history of various measured levels within the drive at various regular time intervals
prior to a trip. The values are frozen when a fault occurs and can be used for diagnostic purposes – see section for further
information.
P0‐41 Critical Fault Counter – Over Current
P0‐42 Critical fault counter – Over Voltage
P0‐43 Critical fault counter – Under Voltage
P0‐44 Critical fault counter – Over Temperature
P0‐45 Critical fault counter – Brake Transistor Over Current
P0‐46 Critical fault counter – Ambient Over Temperature
These parameters contain a record of how many times certain critical faults have occurred during a drives operating lifetime.
This provides useful diagnostic data
P0‐47 Reserved
Reserved Parameter
P0‐48 Reserved
Reserved Parameter
P0‐49 Modbus RTU Communication Error Counter
This parameter is incremented every time an error occurs on the Modbus RTU communication link. This information can be used
for diagnostic purposes.
P0‐50 CAN Open Communication Error Counter
This parameter is incremented every time an error occurs on the CAN Open communication link. This information can be used
for diagnostic purposes.
44
Optidrive ODP‐2 User Guide Revisions 1.30
www.invertekdrives.com
Units
HH:MM:SS
HH:MM:SS
HH:MM:SS
HH:MM:SS
HH:MM:SS
V
V
°C
°C
A
‐
‐
‐
‐
‐
‐
‐
‐
‐
‐
