Invertek Drives OPTIDRIVE P2 Series Easy Start Up Manual page 13

3.4.3. IP66 Units
I
J
Note : Unit shown is a non‐switched unit with optional OLED display
Drive A B
Size
mm in mm in
2 257 10.12 220 8.66
3 310 12.20 277 10.89
Mounting Bolt Sizes
All Frame Sizes
Tightening Torques
Control Terminal Torque Settings :
Power Terminal Torque Settings :
Optidrive ODP‐2 User Guide Revision 1.30
D B A
H
G
D E F
mm in mm in mm
200 7.87 29 1.12 239
252 9.90 33 1.31 251
4 x M4 (#8)
All Sizes : 0.8 Nm (7 lb‐in)
Frame Size 2 : 1.2 – 1.5 Nm (10 – 15 lb‐in)
www.invertekdrives.com
G H
in mm in mm in mm
9.41 188 7.40 178 7.01 4.2
9.88 211 8.29 200 7.87 4.2
F
I J Weight
in mm in kg
0.17 8.5 0.33 4.8
0.17 8.5 0.33 7.3
lb
10.6
16.1
13
