9.2.2. Modbus Control & Monitoring Registers
The following is a list of accessible Modbus Registers available in the Optidrive P2.
•
When Modbus RTU is configured as the Fieldbus option, all of the listed registers can be accessed.
•
Registers 1 and 2 can be used to control the drive providing that Modbus RTU is selected as the primary command source (P1‐12 = 4)
and no Fieldbus Option Module is installed in the drive Option Slot.
•
Register 3 can be used to control the output torque level providing that
The drive is operating in Vector Speed or Vector Torque motor control modes (P4‐01 = 1 or 2)
o
The torque controller reference / limit is set for 'Fieldbus' (P4‐06 = 3)
o
•
Register 4 can be used to control the acceleration and deceleration rate of the drive providing that Fieldbus Ramp Control is enabled
(P5‐07 = 1)
•
Registers 6 to 24 can be read regardless of the setting of P1‐12
Register Upper
Number Byte
Command Control Word
1
2 Command Speed Reference
3 Command Torque Reference
Command Ramp times
4
Error code Drive status
6
7 Output Frequency
8 Output Current
9 Output Torque
10 Output Power
11 Digital Input Status
20 Analog 1 Level
21 Analog 2 Level
22 Pre Ramp Speed Reference
23 DC bus voltages
24 Drive temperature
9.2.3. Modbus Parameter Access
All User Adjustable parameters (Groups 1 to 5) are accessible by Modbus, except those that would directly affect the Modbus communications,
e.g.
•
P5‐01 Communication Protocol Select
•
P5‐02 Drive Fieldbus Address
•
P5‐03 Modbus RTU Baud Rate
•
P5‐04 Modbus RTU Data Format
All parameter values can be read from the drive and written to, depending on the operating mode of the drive – some parameters cannot be
changed whilst the drive is enabled for example.
When accessing a drive parameter via Modbus, the Register number for the parameter is the same as the parameter number,
E.g. Parameter P1‐01 = Modbus Register 101.
Modbus RTU supports sixteen bit integer values, hence where a decimal point is used in the drive parameter, the register value will be
multiplied by a factor of ten,
E.g. Read Value of P1‐01 = 500, therefore this is 50.0Hz.
For further details on communicating with Optidrive using Modbus RTU, please refer to your local Invertek Sales Partner.
46
Optidrive ODP‐2 User Guide Revisions 1.30
Lower Read Notes
Byte Write
R/W Command control word used to control the Optidrive when operating with Modbus
RTU. The Control Word bit functions are as follows :‐
Bit 0 : Run/Stop command. Set to 1 to enable the drive. Set to 0 to stop the drive.
Bit 1 : Fast stop request. Set to 1 to enable drive to stop with 2
Bit 2 : Reset request. Set to 1 in order to reset any active faults or trips on the drive.
This bit must be reset to zero once the fault has been cleared.
Bit 3 : Coast stop request. Set to 1 to issue a coast stop command.
R/W Setpoint must be sent to the drive in Hz to one decimal place, e.g. 500 = 50.0Hz
R/W Setpoint must be sent to the drive in % to one decimal place, e.g. 2000 = 200.0%
R/W This register specifies the drive acceleration and deceleration ramp times used when
Fieldbus Ramp Control is selected (P5‐08 = 1) irrespective of the setting of P1‐12.
The input data range is from 0 to 60000 (0.00s to 600.00s)
R This register contains 2 bytes.
The Lower Byte contains an 8 bit drive status word as follows :‐
Bit 0 : 0 = Drive Disabled (Stopped), 1 = Drive Enabled (Running)
Bit 1 : 0 = Drive Healthy, 1 = Drive Tripped
Bit 2 : No Function
Bit 3 : Drive Ready, 1 = Drive Inhibit
Bit 4 : Maintenance Time Not Reached, 1 = Maintenance Time Reached
Bit 5 : 0 = Not In Standby (Sleep), 1 = Standby (Sleep) mode active
Bit 6 : No function
Bit 7 : No Function
Bit 8 : No Function
The Upper Byte will contain the relevant fault number in the event of a drive trip.
Refer to section 11.1 for a list of fault codes and diagnostic information
R Output frequency of the drive to one decimal place, e.g.123 = 12.3 Hz
R Output current of the drive to one decimal place, e.g.105 = 10.5 Amps
R Motor output torque level to one decimal place, e.g. 474 = 47.4 %
R Output power of the drive to two decimal places, e.g.1100 = 11.00 kW
R Represents the status of the drive inputs where Bit 0 = Digital Input 1 etc.
R Analog Input 1 Applied Signal level in % to one decimal place, e.g. 1000 = 100.0%
R Analog Input 2 Applied Signal level in % to one decimal place, e.g. 1000 = 100.0%
R Internal drive frequency setpoint
R Measured DC Bus Voltage in Volts
R Measured Heatsink Temperature in °C
www.invertekdrives.com
nd
deceleration ramp.
