VAA-4E4A-G20-ZEJ/M2L-P7-GEB
Product Description
Motor Direction of Rotation Indicator
LED DIR
Yellow
On
Off
Status Indicators for Sensors IN1, IN2, IN3, IN4
The LED IN1 for input 1, LED IN2 for input 2, LED IN3 for input 3, and LED IN4 for input 4
indicate the switch states of the inputs.
Display of the Inputs
LED IN1
LED IN2
LED IN3
LED IN4
Yellow
On
Off
2.4

Interfaces and Connections

Flat Cable Specification
The AS-Interface motor control module is compatible with the AS-Interface standard cable in
accordance with IEC 62026-2.
The following AS-Interface cable types with "UL Recognized" approval are available:
AS-Interface Cable Types with UL Approval
Pepperl+Fuchs
Designation Color
VAZ-FK-R-YE Yellow
VAZ-FK-R-BK Black
VAZ-FK-PUR-YE Yellow
VAZ-FK-PUR-BK Black
Input/Output Connections
The sensors and motors are connected to the motor control module via cables with round M8
connectors:
Sensors: socket, 4-pin
Motors: socket, 5-pin
The cable length is 0.5 m.
Status
Direction of rotation to the right (ITOH Denki)
Direction of rotation to the left (ITOH Denki)
Status
Input is set (high)
Input is not set (low)
Sheathing/wire
insulation material Cross section UL "Cable Style"
TPE/TPE 2x 1.5 mm
TPE/TPE 2x 1.5 mm
PUR(TMPU)/TPM 2x 1.5 mm
PUR(TMPU)/TPM 2x 1.5 mm
Approval
2103
2103
20549
20549
