VAA-4E4A-G20-ZEJ/M2L-P7-GEB
Product Description
Motor Supply from Auxiliary Power
The motors are supplied with power directly from the AUX external auxiliary power and this
cannot be switched. The voltage is always present at contacts 1 and 3 of the 5-pin M8
connector.
Connector Assignment
Connection for
Sensor
Motor
10
Connector type/assignment
Connector
Input: in accordance with IEC/EN 61076-2-104
M8, 4-pin, socket, screw-locking, coding A
4 2
Suitable counterpart connector:
3 1
M8, 4-pin, plug, screw-locking, coding A
IN1/IN3
1: IN+ sensor supply
2: IN3: Input
3: IN- sensor supply
4: IN1: Input
Motor: in accordance with IEC/EN 61076-2-104
4 2
M8, 5-pin, socket, screw-locking, coding B
3 1
Suitable counterpart connector:
M8, 5-pin, plug, screw-locking, coding B
5
1: MOT+ motor supply
2: DIR direction of rotation
3: MOT- (=AUX-) motor supply
4: RUN motor start
5: SPEED velocity signal
IN2/IN4
IN+ sensor supply
IN4: Input
IN- sensor supply
IN2: Input
