Danfoss VLT FC 100 Series Manual page 77

FC 100/ 200/ 300 DeviceNet
The effect of control mode upon the function of par. 8-53
lect
:
Digital Input
If
will control the start and reversing functions
Bus
If
vated only when given via the control word.
Logic AND
If
be activated to perform the function.
Logic OR
If
signal will activate the function.
The effect of control mode upon the function of par. 8-55
Select
:
Digital input
If
will control the set-up and preset reference
functions.
[0] is selected, the terminals
[1] is selected, commands will be acti-
[2] is selected, both signals must
[3] is selected, activation of one
[0] is selected, the terminals
MG.33.D3.02 - VLT ® is a registered Danfoss trademark
8. Troubleshooting
Start Select
and 8-54
Digital input [0]
Par. 8-53/54 setting:
Terminal Bit 06/15 Function
0 0 Stop/Anti-clockwise
0 1 Stop/Anti-clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise
Bus [1]
Par. 8-53/54 setting:
Terminal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Start/Clockwise
1 0 Stop/Anti-clockwise
1 1 Start/Clockwise
Logic AND [2]
Par. 8-53/54 setting:
Terminal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Stop/Anti-clockwise
1 0 Stop/Anti-clockwise
1 1 Start/Clockwise
Logic OR [3]
Par. 8-53/54 setting:
Terminal Bit 02/03/04 Function
0 0 Stop/Anti-clockwise
0 1 Start/Clockwise
1 0 Start/Clockwise
1 1 Start/Clockwise
Set-up Select Preset Reference
and 8-56
Par. 8-55/56 setting: Digital input [0]
Terminal Bit 00/01, Function
13/14
Msb Lsb Msb Lsb Preset ref., Set-up no.
0 0 0 0 1
0 0 0 1 1
0 0 1 0 1
0 0 1 1 1
0 1 0 0 2
0 1 0 1 2
0 1 1 0 2
0 1 1 1 2
1 0 0 0 3
1 0 0 1 3
1 0 1 0 3
1 0 1 1 3
1 1 0 0 4
1 1 0 1 4
1 1 1 0 4
1 1 1 1 4
Reversing Se-
8
77
