4. How to Control the Frequency Converter
Bit 6, Ref from net:
Bit 6 = "0" means that the reference comes from inputs to the drive.
Bit 6 = "1" means that the reference comes from DeviceNet.
Bit 7, At reference:
Bit 7 = "0" means that the motor is running, but that the present speed is different from the preset
speed reference, i.e. the speed is being ramped up/down during start/stop.
Bit 7 = "1" means that the drive and reference speeds are equal.
Bit 8 - 15, State attribute:
4
(Instance 71 only)
Represents the state attribute of the drive, as
indicated in the table to the right:
For more detail of the actual output speed, see the section
20/70 and 21/71
30
.
MG.33.D3.02 - VLT ®
Bit Num- Meaning
ber
8 (Vendor specific)
9 Start up
10 Not ready
11 Ready
12 Enabled
13 Stopping
14 Fault stop
15 Faulted
Actual Output Speed under Instances
is a registered Danfoss trademark
FC 100/ 200/ 300 DeviceNet
