FC 100/ 200/ 300 DeviceNet
5.3.5. Class ID 04h Assembly Object
This is a standard DeviceNet Object for transfer of the I/O Instances (Process Data) described in
the section "How to control the Frequency Converter". Using this it is possible to send or read any
of the defined Instances, either by polling or explicit messaging.
The attributes supported for this class are listed below.
5.3.6. Class ID 0x04
Attrib-
ute
3
In-
stance
20
21
70
71
100
101
150
151
5.3.7. Class ID 05h Connection Object
This is a standard DeviceNet Object for allocation and managing I/O and explicit messaging con-
nections. For this class three Instances are supported: Explicit Messages, Polled I/O and Change
of State connections.
The attributes supported for the different instances are listed below.
Access Name Data
type
Set Data ARRAY
Access Size Description
Set 2 Words DeviceNet AC/DC Profile
Set 2 Words DeviceNet AC/DC Profile
Get 2 Words DeviceNet AC/DC Profile
Get 2 Words DeviceNet AC/DC Profile
Set 2 Words Danfoss specific, no PCD
Words
Set 4 Words Danfoss specific, 2 PCD Words Instance 101/151
Get 2 Words Danfoss specific, no PCD
Words
Get 4 Words Danfoss specific, 2 PCD Words Instance 101/151
MG.33.D3.02 - VLT ® is a registered Danfoss trademark
5. How to Access the Parameters
Min/ Units Default Description
Max
Parameters 10-10 selec-
tion:
Instance 20/70
Instance 21/71
Instance 20/70
Instance 21/71
Instance 100/150
Instance 100/150
