FC 100/ 200/ 300 DeviceNet
8-55 Set-up Select
Option:
[0]
[1]
[2]
*
[3]
8-56 Preset Reference Select
Option:
[0]
[1]
[2]
*
[3]
Select
fieldbus/serial communication port, AND additionally via one of
the digital inputs.
Select
fieldbus/serial communication port OR via one of the digital in-
puts.
Function:
Select control of the frequency converter set-up selection via
the terminals (digital input) and/or via the fieldbus.
Digital input
Bus Activates the set-up selection via the serial communication port
or fieldbus option.
Logic AND Activates the set-up selection via the fieldbus/serial communi-
cation port, AND additionally via one of the digital inputs.
Logic OR Activate the set-up selection via the fieldbus/serial communica-
tion port OR via one of the digital inputs.
NB!
This parameter is active only when par. 8-01
control word
.
Function:
Select control of the frequency converter Preset Reference se-
lection via the terminals (digital input) and/or via the fieldbus.
Digital input
Bus Activates Preset Reference selection via the serial communica-
tion port or fieldbus option.
Logic AND Activates Preset Reference selection via the fieldbus/serial com-
munication port, AND additionally via one of the digital inputs.
Logic OR Activates the Preset Reference selection via the fieldbus/serial
communication port OR via one of the digital inputs.
NB!
This parameter is active only when par. 8-01
control word .
MG.33.D3.02 - VLT ® is a registered Danfoss trademark
Logic AND
[2] to activate the Reverse command via the
Logic OR
[3] to activate the Reverse command via the
NB!
This parameter is active only when par. 8-01
trol Site Digital and control word
is set to [0]
Control Site
Control Site
6. Parameters
Con-
.
Digital and
is set to [0]
Digital and
is set to [0]
6
