FC 100/ 200/ 300 DeviceNet
5.3.13. Class ID 28 Motor Data Object
In this object, the current motor data can be configured and read out. The Instances, attributes
and services supported for this class are listed below.
5.3.14. Class ID 0/28 Motor Data Object
Attrib-
ute
3
6
7
8
9
12
15
Access Name Data Generic
type maximum
values
Get/set Motor USINT 7
type
Get/set Rated UNIT 0-100.00
current
Get/set Rated UNIT 200-500
voltage
Get/set Rated UDINT 0-18500
power
Get/set Rated UNIT 1-1000
frequen-
cy
Get/set Pole UINT
count
Get/set Base UNIT 100-60000
speed
MG.33.D3.02 - VLT ® is a registered Danfoss trademark
5. How to Access the Parameters
Units Default Description
7 7 = Squirrel Cage Induction Motor
100mA Drive dependent Stator Current rating (from motor
nameplate)
volt Drive dependent Base Voltage rating (from motor
nameplate)
Watt Drive dependent Power rating at rated frequency
(from motor nameplate)
Hz Drive dependent Elec. frequency rating (from motor
nameplate)
Drive dependent Number of poles in the motor
RPM Drive dependent Nominal motor speed (from motor
nameplate)
Parameter
reference
1-11
1-24
1-22
5
1-20
1-23
1-39
1-25
