6. Parameters
[3]
[4]
[5]
[7]
[8]
[9]
[10]
6
8-05 End-of-Timeout Function
Option:
[0]
[1]
8-06 Reset Control Word Timeout
Option:
[0]
54
Jogging
Max. Speed
Stop and trip
Select set-up 1
Select set-up 2
Select set-up 3
Select set-up 4
Hold set-up
*
Resume set-up
*
Do not reset
MG.33.D3.02 - VLT
Select the time-out function. The time-out function activates
when the control word fails to be updated within the time period
Control Word Time-out Time
specified in par. 8-03
Off
-
[0]: Resume control via serial bus (Fieldbus or
standard) using the most recent control word.
Freeze output
-
[1]: Freeze output frequency until com-
munication resumes.
Stop
-
[2]: Stop with auto restart when communication
resumes.
Jogging
-
[3]: Run the motor at JOG frequency until
communication resumes.
-
Max. freq.
[4]: Run the motor at maximum frequency
until communication resumes.
Stop and trip
-
[5]: Stop the motor, then reset the fre-
quency converter in order to restart: via the fieldbus,
via the reset button on the LCP or via a digital input.
Select set-up 1-4
-
[7] - [10]: This option changes the
set-up upon reestablishment of communication follow-
ing a control word time-out. If communication resumes
causing the time-out situation to disappear, par. 8-05
End-of-time-out Function
the set-up used before the time-out or to retain the
set-up endorsed by the time-out function. Note the
following configuration required in order to change the
set-up after a time-out: Set Par. 0-10
Multi set-up
[9], and select the relevant link in par.
This Set-up Linked To
0-12
Function:
Select the action after receiving a valid control word following a
time-out. This parameter is active only when par. 8-04 is set to
[Set-up 1-4].
Retains the set-up selected in par. 8-04 and displays a warning,
until par. 8-06 toggles. Then the frequency converter resumes
its original set-up.
Resumes the set-up active prior to the time-out.
Function:
®
is a registered Danfoss trademark
FC 100/ 200/ 300 DeviceNet
.
defines whether to resume
Active set-up to
.
