Initial Setup Procedure; Graphic Screens; "Air Handling Unit Overview" Screen - Frick Quantum ACUair Service Manual

S90-500 O
Page 6

INITIAL SETUP PROCEDURE

1. Panel Setup is performed first. Panel Setup is
used to setup panel features and options that later
can be changed by an operator. Features such as the
panel time, and screen color are changed here.
2. Unit Board Setup is performed next. Unit Board
Setup is used to setup the customer specific control
features and options to be used by a unit controller
board. This setup should not need to be changed by
operators. Unit Board Setup
Also called the "Home" screen. This screen shows an
overview of the most important information about the
units. This screen is shown when power is first turned on
and when a key is pressed after the screen saver has
turned off the backlight. The "Air Handling Unit Overview"
screen is continuously updated and provides the current
status of each unit's condition and performance.
The following information is shown on this screen:
· ID - The identification number of the unit
displayed.
· Name - The identification name that describes
the unit that is displayed.
· Status The present operation status of the unit.
· Mode - The present mode of the unit, either
Cleanup or Process.
· Actual - The current reading of the present
analog control value.
®
FRICK QUANTUM™ ACUair
OPERATION
is intended to be

GRAPHIC SCREENS

"AIR HANDLING UNIT OVERVIEW" SCREEN

®
CONTROL PANEL
accessed and performed
Representative or Distributor.
3. Calibrate the control devices.
4. From Control Setup enter and setup the control
settings.
5. From Security Setup, establish the desired access
rights of the operators.
The panel now provides quick access to the most
important information and controls of the units and their
subsystems.
· Setpoint - The setpoint that is currently being
maintained.
Several types of failures and alarms are also
indicated on this
communicating with the Quantum , the information
specific to that unit is shown in red text. After
communications with the unit has been restored, the
text color will return to black. In addition, a list of the
units that have previously been communicating with
the Quantum is saved even when powered off. If a
unit in that list does not respond to the Quantum
during the starting sequence, the words Not Found
are displayed in red in place of that unit s name.
Once a proper connection with the unit is made,
logging in to the unit will replace the words Not
Found with the unit s name. Finally, when a unit is in
an alarm condition, a red circle flashes in the small
box between "Status" and "Mode" until the alarm is
cleared.
only by a Factory
screen. If a unit stops
