The Quantum™ has the capability of being modified by the user/owner in order to obtain different performance
characteristics. Any modification to the standard default settings may have a severe negative impact on the
operation and performance of the equipment. Any modification to these control settings is the sole responsibility of
the user/owner and Frick
modification of these settings may cause improper operation and performance that results in property damage,
personal injury or death. It is the responsibility of the user/owner to evaluate and assess the consequences of their
actions prior to modifying the controls for this unit.

OVERVIEW OF OPERATOR INTERFACE

The panel user interface has been designed to allow an
operator to efficiently access and control the operation of
the units. The control panel screen is used for graphic
displays. By pressing a key on the keypad, the labeled or
described function is recognized by the control processor.
The following information is presented to help the operator
interact with the graphic screens and the Quantum
®
ACUair control panel. This manual is intended to
describe all presently available features.
®
FRICK QUANTUM™ ACUair
®
disclaims any liability for the consequences of these modifications. It is possible that the
®
CONTROL PANEL
OPERATION
Warning
!
Operator access to this system is through various
screens. A screen is the physical representation of data
on the display. Icons have been used to help an operator
quickly identify functions. An icon is a small graphic
symbol representation. Each screen has a title area. The
title is descriptive of the screen. The current date and time
is shown in this title area. The day of the week, Sunday
(Sun.) through Saturday (Sat.) is displayed. The month of
the year from January (Jan.) to December (Dec.) is
displayed. The day of the month from 1 to 31 and the year
from 0001 to 9999 is displayed. The time displayed is the
current time in 24 hours (military) format. The hours,
minutes and seconds are displayed. The labeled keys on
the panel keypad provide quick access to the operator's
needs. By pressing a labeled key on the keypad, the
corresponding function is recognized. Most of the screens
have screen keys that describe or show a function that is
recognized when the coinciding key found at the right of
the display screen is pressed. The screen keys provide
access to other screens or commands. For easier
viewing, related information is separated into boxes. The
setup and setpoint entry is separated into logical control
components. Setup selection of features and options has
been provided to prevent the operator from unnecessary
viewing and entering of unused control settings. The
required control settings are clearly presented. To further
assist the operator, an on-line help is provided.
Sometimes selections appear differently to indicate that
the feature is unavailable.

OPERATOR ACCESS
