Anchor the Cabinet
If the system is delivered installed in a mounting rack, anchor the cabinet before
installing rectifiers and batteries. Refer to the accompanying system installation
guide for rack feet diagrams and floor loading concerns.
Equipment Rack "Frame Ground"
Connections are located at rear of the rectifier rack with chassis studs
provided in the AC input chamber. Refer to the NEC and any local codes
practices to determine the appropriate wire size. Use of paint-penetrating
washers, abrasive compounds, or other means to achieve a reliable frame
ground is recommended.
Converter Shelf Installation
If Flatpack DC-DC converters are to be installed, refer to the manual
accompanying the converters for instructions on mounting and making system
connections.
Installation Guide Flatpack2 -48V 150A ~ 2029242 R2, May 2008
9
