3. Mechanical Installation

U
SE OF FULLY INSULATED TOOLS IS REQUIRED WHEN WORKING WITH ANY POWERED
.
CIRCUITS
THE SYSTEM IS TO BE MOUNTED OVER A CONCRETE SURFACE ONLY AND INSTALLED IN
R
ESTRICTED
.
AND KEY
The following tools are required for the installation:
Standard wrench and/or socket set (1/4" to 1")
o
Torque wrench, 10-40 Ft-lb range.
o
Torque screwdriver, 5-10 in-lb range.
o
Small flat blade screwdriver (3/32" wide)
o
Standard blade screwdriver and Phillips tip screwdriver
o
Wire cutters / strippers
o
Fork-lift truck or similar heavy equipment handling transport
o
Hoist with lifting straps
o
Electric drill and appropriate bits (a hammer drill may be required for concrete
o
flooring)

System Unpacking

An individual Flatpack2 -48V 150A unit is shipped in a box with protective
packing material. If pre-installed in a cabinet or rack, the assembly is wrapped
with a shroud of high-strength plastic and bolted to a wooden pallet with four
anchors. Rectifier modules and expansion options are packed in separate
cartons.
Exercise care when unpacking and setting the equipment in place.

Rack Mounting

The Flatpack2 -48V 150A system can be installed in a rack or an enclosure. The
mounting brackets are pre-installed at the factory and designed to be mounted
within a standard EIA 19" or 23" rack. Systems are designed to be mid-mounted.
Other mounting configurations may require additional support brackets.

Rack Installation

1) Use proper lifting equipment to position the Flatpack2 -48V 150A system
so that the holes in the support bracket are aligned with the correct
mounting holes in the rack.
2) Use rack screws to connect the system brackets to the desired positions
of the rack.
8
A L (RAL). A
CCESS OCATIONS CCESS MUST BE LIMITED BY USE OF TOOL
Installation Guide Flatpack2 -48V 150A ~ 2029242 R2, May 2008
