NOTE: I
,
F USING EXTERNAL BATTERY CONNECTIONS BOARDS
SUCH AS THOSE PROVIDED WITH A
,
SYMMETRY MONITORING KIT
DO NOT CONNECT MORE THAN ONE TEMPERATURE PROBE TO EACH OF
. C
15-
CON6/CON7
THE BOARDS
ONNECT A SINGLE PROBE EITHER TO THE
PIN SERIAL PORT
OR TO
.
9
10
THE SENSE INPUTS TO TERMINALS
AND
OF THE TERMINAL BLOCK
Symmetry Terminations
Symmetry capability is facilitated by a symmetry monitoring kit. A battery
connection board is mounted near the batteries using a bracket. The serial port
connector (DE15) connects the board to either CON3 or CON4 on the rear of the
Smartpack controller.
Up to two battery boards may be installed for each
controller.
In this case, temperature probes must connect to the battery
connection board (one per board). Battery symmetry harness connections will
vary depending on the desired configuration. Refer to the symmetry kit manual
(#251491.033) for more details and installation instructions.
24
Installation Guide Flatpack2 -48V 150A ~ 2029242 R2, May 2008
