Head section Thigh section
Fixed seat support
Lower leg section
2. General functionality
description
Design configuration and functionality
The lying surface and its four sections
In the standard version, the lying surface comes with comfort
wooden slats (may be supplemented with a metal lying surface
or special suspension systems) and is made up of four sections:
head section, fixed seat support, upper - and lower leg section.
The complete frame of the lying surface has been welded from
steel tubes and stove-enameled using a PES-powder coating.
The electrical stepless variable height adjustment of the lying
surface is controlled by means of 24 V-direct current motors and
the smooth-running keys of the hand control. The head section
can be electronically adjusted. The leg part consits of a two-part
feet bracket. The stepless adjustment of the position can be
made by means of the hand control. The control via the electro-
nic hand control allows also for an automatic triple function for
the stretched elevation of the legs towards the heart- and knee
bend. In the event of a blackout, the back- and leg part can be
lowered by means of a 9 V battery.
