3.4 The lockable hand control, fault safe operation
The extra-large, easily operable 6 buttons positioned on the ergo-
nomically shaped hand control provide the main functions and
can be controlled at the touch of a finger. Each of the operating
buttons is labeled with appropriate symbols.
As long as the button for the adjustment of the actuators is pus-
hed, the actuators are operating. A spiral-shaped cable provides
the necessary clearance whilst the operation is being performed.
The rear side mounted clip is rotatable by 90° on
both sides. The radius is exactly in line with the radius of the
side rail and the lifter, so that there are no unsteady clearances.
The possibly disturbing position of the hand control while perfor-
ming cleaning or maintaining operations can be avoided simply
by turning it to another side or easily clipping it onto any spot
of the bed.
The Bock hand control
Function button 1
Function button 2
Function button 3
Function button 4
Function button 5
Function button 6
Head rest up
Head rest down
Foot part up
Foot part leg part down
Lying surface up
Lying surface down
> Bock Top Advice
The drives with the
E-transformer 24V: Due
to the low standby- mode
consumption (max. W)
and the ideal efficiency of
the power plug, the bed is
remakable ecomomic in
the energy consumption.
Drives with the mains iso-
lation: Due to the mains
isolation the bed is com-
pletly smog free and
remakable ecomomic in
the energy consumpti-
on. Electricity is only used
when the bed is adjustes
by the hand control
* Bock Hazard Note
The high safety standards
of Hermann Bock´s health
care beds is not under-
stood as a exclusion of
all risks. The strict com-
pliance with all specifica-
tions and instructions con-
cerning the intendes use
provide the prevention of
all risks.
