- Page 1 Assembly Instruction and User Manual adilec...
- Page 2 Dear valued customer, with your decision to purchase a therapy and rehabilitation bed from Hermann Bock GmbH, you will receive a durable care product with superior functionality at the highest safety level. Our electrically operated nursing care beds guarantee an optimal lying comfort and enable a professional care at the same time. This product was designed with a focus on persons in need of care, whose confidence must be reinforced and whose life needs protection.
-
Page 3: Table Of Contents
The hand control ..................... 18 4 Assembly and operation ..................20 Technical data ....................20 adilec 280 ......................21 adilec 280 in individual parts ................21 adilec 280 becomes operational ..............22 Change of location ..................24 Transport, storage and operating conditions ..........24 Function notes .................... -
Page 4: Preface And General Instructions
17. adilec 280 is a special bed for the optimal care of severely overweight and obese patients. It is suitable for use in therapy and rehabilitation as well as for care at home. With adilec 280, people with a body weight of up to 280 kg can be cared for comfortably. -
Page 5: Definition Of Person Groups
– under certain circumstances adilec 280 can be used (if necessary) for medical pur- poses with other electric medical equipment (e.g. suction devices, ultrasonic hu- midifier, food systems, anti-bedsore systems, oxygen concentrators and similar de- vices). In this event, deactivate all bed functions for the duration of the application via the integrated locking function. -
Page 6: Safety Instructions
Safety instructions The intended use/operation of all moving parts is as important for the safety of the per- sons in need of care as well as for the relatives and the caregivers/nursing staff to avoid potentially dangerous situations. This requires the correct assembly and operation of the bed. -
Page 7: Service Life / Warranty
Bock safety note When the user, e.g. the nursing staff or caring relatives, leaves the room, the lying surface should be moved to the lowest position in order to minimise the risk of injury if the patient falls out. -
Page 8: Requirements For The Installation Location
Requirements for the installation location The company Hermann Bock GmbH is not liable for damages which might arise from the daily usage on the floor. To avoid floor indentations, floor should correspond to the recommendations of the FEB - Fachverband der Hersteller elastischer Bodenbeläge e.V. (Association of Elastic Floor Coverings Manufacturers). - Page 9 IPX4 Protection of electrical equipment against splashing water Symbol for maximum patient weight Symbol for safe working load Maximales Bettengewicht inklusive sichere Arbeitslast Symbol for the labelling of a medical device Patient population Follow the instructions appropriate for mattress size and thickness Address of the manufacturer Anschrift des gesetzlichen Vertreters Schweiz...
-
Page 10: General Description Of The Functions
General description of the functions 1 Back rest 2 Seat part (fixed) 3 Upper leg rest 4 Lower leg rest Construction design and function The lying surface with 4 function areas The lying surface consists of a solid wood panel as standard and is divided into four func- tional areas: back rest, fixed seat part, upper and lower leg rest. - Page 11 The side rails Each nursing care bed is equipped with two integrated side rails on both sides at a special safety height. The side rails can be lifted and lowered through a rail. The sliding pieces run particularly smoothly and quietly with an impact damper, and the ends are fitted with attractive looking caps.
- Page 12 Hazard note from Bock Use only original Bock side rails, which are available as accessories for every nursing care beds. Use only technically flawless and non-damaged side rails with the permissible gap dimensions.
- Page 13 Fig. 1: Continuous wooden side rail, divided into two parts Description All dimensions in mm. Part numbers * Depending on the length of the lying surface Designation item no. The single post at the head and foot end is optional. Continuous wood side rail The dimension in brackets is optional Two-part (Fig.
-
Page 14: Electric Parts
After a cooling down time of approx. one hour, the power supply will be automatically restored. Hazard note from Bock The 9-volt batteries in the control unit should be checked once a year for their functionality and... -
Page 15: Caution: Electric Drive
Hazard note from Bock The motors comply with splash water protection IPX4. The cables must not be crushed. Adjust- ment of moving parts may only be used for the intended use. Hermann Bock GmbH assumes no liability for unauthorized technical changes. -
Page 16: The Drives With Mains Isolation
The drives with mains isolation Hermann Bock GmbH equips the adilec nursing care bed with drive systems from the com- pany Limoss. The double drive for step-less adjustment of lying surfaces and the linear drive as single drive for height adjustment of the lifting frames each consist of four main components. -
Page 17: Connections Of The Double Drive
Connections of the double drive Operating status display of the external SMPS unit The SMPS (switch-mode power supply) unit has an LED that can indicate the following operating states: ▪ LED On: Ready for operation ▪ LED Off: Discharged, not connected ▪... -
Page 18: The Hand Control
Lower leg rest upwards Lower leg rest downwards Lying surface upwards Lying surface downwards Lighting on/off Hazard note from Bock Do not exceed the maximum duty cycle of 2 minutes. Observe a subsequent break of at least 18 minutes by all means. - Page 19 Hand control - lock functions The hand control comes with an integrated locking mechanism that can be activated and deactivated with the corresponding key. To lock the entire electrical function, insert the key in the keylock on the backside and turn the lock function on or off with a correspond- ing twist of the key.
-
Page 20: Assembly And Operation
Assembly and operation Technical data Technical data adilec 280 Lying surface dimension: cm 100 / 120 x 200 Outer dimension: cm 116 / 136 x 223 Safe working load: kg Max. weight of person: kg Height adjustment: cm 40 - 81 Max. -
Page 21: Adilec 280
280 Special features adilec 280 has a special and extremely stable ball guide system as a special quality feature. The adjustment height of the bed is extremely large and particularly practical. The electri- cal adjustment of the back and leg sections of the 4-fold lying surfaces is carried out via the hand control with automatic 3-fold function. -
Page 22: Adilec 280 Becomes Operational
280 becomes operational Before proceeding with the further assem- bly, all packaging residues must be com- pletely removed. – The wooden end panel is to be pulled down from the lifting col- umn on both sides. – Pull both lifting columns off the metal transport lock. - Page 23 Put the wooden end panels over the lifting columns. The lifting columns must engage in the recess inside the wood end panel. Screw the wooden end panels firmly to the lying surface on all four sides. (M8x35 screws). Fit the wooden side panels to the lying sur- face, with the soft edge facing upwards.
-
Page 24: Change Of Location
Change of location If the bed must be moved to another location, please follow these safety instructions: – bring the lying surface to the lowest position. – disconnect the mains plug before moving and secure the power cable against fall- ing and being run over –... -
Page 25: Troubleshooting
To adapt each nursing care bed more closely to each patient’s individual needs, Hermann Bock GmbH offers practical accessories to promote patient mobility. These accessories can be quickly and easily installed at their predetermined attachment points on the nurs- ing care bed. Naturally, each additional piece of equipment meets Bock’s highest stand-... -
Page 26: Special Dimensions
In addition to the standard accessories provided as basic equip- ment for each nursing care bed, Bock also offers an extensive range of optional extra ac- cessories. The available extras vary by bed model, and are adapted to each model’s spe- cific functions and location of use. -
Page 27: Assembly Accessories
Make sure to only use mattress with a required mat- tress height as described by the company Bock. You can find this information in section 5.3. ATTENTION: The lifting pole must not swing outside of the lying surface! Under normal use conditions, the triangle grip has a service life of approximately 5 years. -
Page 28: Mattresses
A detailed overview of accessories and extras available for your bed model is provided on a separate data sheet. Hermann Bock cannot be held liable for any acci- dents, damages or hazards that may result from use of other accessories! -
Page 29: Cleaning, Maintenance And Disinfection
Cleaning, maintenance and disinfection The individual bed elements consist of high quality materials. The surfaces of the steel tubes is covered with a durable polyester-powder coating. All surfaces of the wooden parts are surface-sealed with an ecologically coating that is low on harmful substances. All bed elements are easy to clean and cared for using wipe and spray disinfection means according to the applicable cleaning requirements with respect to the various areas of application. -
Page 30: Avoidance Of Hazards
Hazard note from Bock Use of abrasive cleansers and/or detergents containing grinding particles, cleaning pads or stain- less steel cleaners for the cleaning is absolutely not recommended. Neither use organic solvents such as halogenated/aromatic hydrocarbons and ketones nor detergents containing acid or al- kaline. -
Page 31: Guidance And Manufacturer's Declaration
Guidance and manufacturer's declaration Guidelines and manufacturer declaration – Electromagnetic emissions The nursing care bed is intended for use in an environment meeting the criteria listed below. The customer or user of the nursing care bed should verify that the bed is being operated in an appropriate environment. Emitted interference measure- Electromagnetic environment –... -
Page 32: Regular Inspections With Service
In the event that no person on the part of the user is eligible for the regular inspections or is commissioned, the Bock service offers you the assumption of the regular inspections with simultaneous control and observance of the corresponding intervals for a fee. - Page 33 For support purposes, Hermann Bock GmbH will provide you with the inspection list in the assembly instruction and user manual for carrying out all the necessary tests. Please copy the checklist as a form for your inspection.
- Page 34 Inspection checklist for Bock Nursing care beds Page 1 of 2 Publication date: 01/09/2021 / Ver. 08 Model number / Year of man- ufacture: Serial/Inventory no.: Manufacturer: Hermann Bock GmbH Visual/Functional inspection: Description General: ☐ ☐ Type plate/Sticker present on bed and legible? ☐...
- Page 35 Inspection checklist for Bock Nursing care beds Page 2 of 2 Publication date: 01/09/2021 / Ver. 08 Client: Address: Location: Plastic end caps and mechanical fasteners (screws, bolts etc.) complete and free of de- ☐ ☐ fects? ☐ ☐ Head and foot end panels firmly seated and free of damage? Back/leg rest adjustment and special functions working correctly and without obstruc- ☐...
- Page 37 Please note that training, spare parts supply, repairs, inspections and other services can only be guaranteed by our authorised personnel and our sales partners. Otherwise, all warranty claims will be void. A listing of our current distributors can be found under https://en.bock.net/contact/distribution-partners/ © registered trademark 890.02112 Current as of: 2023-08...
