Example:
Parameter 201: minimum frequency, conversion factor
0,1. If parameter 201 is to be set to 10 Hz, a value of
100 must be transferred, since a conversion factor of
0,1 means that the transferred value will be multiplied
by 0.1. A value of 100 will thus be understood as 10.
Addressing by unit ID
2. Process-bytes
The process byte block is divided into two blocks each
of 16 bits, which always come in the sequence stated.

Control word according to Fieldbus Profile Standard

(parameter 512 = Fieldbus Profile) The control word
is used for transmitting commands from a master
(e.g. a PC) to a slave (FC motor).
Bit Bit = 0
00 OFF 1
01 OFF 2
02 OFF 3
03 Motor coasting
04 Quick-stop
05 Freeze output frequency Ramp enable
06 Ramp stop
07 No function
08 Jog 1 OFF
09 Jog 2 OFF
10 Data not valid
11 No function
12 No function
13 Setup 1
14
15 No function
MG.03.H3.02 - VLT is a registered Danfoss trademark
The unit ID is printed on the label on the plastic
cover under the lid of the electronics box. The three
groups of unit ID each with three digits must be
converted to Hex. The desired address is added as
the last byte. The frame is sent to the bus address
parameter(s) 500 (and 918) via a broadcast.
PKE: Write to parameter No. 500 or 918
IND: Not Used
Control
telegram
(master→slave)
Reply telegram
(slave→master)
because there is no 24V external connection to supply
the FCM 300 control, which is required to activate
the FCM 300 again via input signal.
Bit 00, OFF1/ON1:
An ordinary ramp stop which uses the ramp time
in parameters 207/208. Bit 00 = "0" leads to
a stop. Bit 00 = "1" means that the frequency
Bit =1
converter will be able to start if the other conditions
ON 1
for starting have been fulfilled.
ON 2
ON 3
Bit 01, OFF2/ON2:
Enable
Coasting stop. Bit 01 = "0" leads to a coasting stop.
Ramp
Bit 01 = "1" means that the frequency converter
is able to start, provided the other conditions
Start
for starting have been fulfilled.
Reset
ON
Bit 02, OFF3/ON3:
ON
Quick-stop, which uses the ramp time in parameter 212.
Valid
Bit 02 = "0" leads to a quick-stop. Bit 02 = "1" means
Slow down /
that the frequency converter is able to start, provided
Relay 123 / Digital
the other conditions for starting have been fulfilled.
output terminal 9
Bit 03, Coasting/enable:
Catch-up / Relay
Coasting. Bit 03 = "0" leads to a stop. Bit 03 =
123
Setup 2 "1" means that the frequency converter is able to
start, provided the other conditions for starting are
Reversing
fulfilled. Note: In parameter 502 the choice is made
®
VLT FCM Series
PCD1
Control word
Status word
NB!:
The use of Bit 00, Bit 01 and Bit 02 for
switching off the power supply (by use of
relay) will require a separate power on. This
PCD2
Reference
value
Given output
frequency
