Danfoss VLT FCM Series Manual page 53

332 Terminal 2, analogue/digital input
(DIGITAL INPUT 2)
333 Terminal 3, digital input
(DIGITAL INPUT 3)
334 Terminal 4, digital input
(DIGITAL INPUT 4)
335 Terminal 5, digital input
(DIGITAL INPUT 5)
Parameter
Digital input on terminal no.
Settings:
No function
Reset
Coasting stop, inverse
Reset and coasting stop, inverse
Quick-stop, inverse
DC-braking, inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Start clockwise, on
Start counter-clockwise, on
Jog
Freeze reference
Freeze output
Speed up
Speed down
Selection of Setup
Catch-up
Slow-down
Preset reference
Preset reference, on
Precise stop, inverse
Pulse reference
Pulse feedback
Analogue reference
Analogue feedback
Reset and start
Freeze reference and start
Ramp 2
Start-ref bit 1
Start-ref bit 2
Start-ref bit 3
Function:
In parameters 332-335 it is possible to choose
between the different possible functions related to
the inputs on terminals 2-5. The function options
are shown in the table below.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.03.H3.02 - VLT is a registered Danfoss trademark
(NO OPERATION)
(RESET)
(MOTOR COAST INVERSE)
(RESET & COAST INV.)
(QUICK STOP INVERSE)
(DC-BRAKE INVERSE)
(STOP INVERSE)
(START)
(LATCHED START)
(REVERSING)
(START REVERSING)
(ENABLE FORWARD)
(ENABLE REVERSE)
(JOGGING)
(FREEZE REFERENCE)
(FREEZE OUTPUT)
(SPEED UP)
(SPEED DOWN)
(SETUP SELECT)
(CATCH UP)
(SLOW DOWN)
(PRESET REF.)
(PRESET REF. ON)
(PRECISE STOP)
(PULSE REFERENCE)
(PULSE FEEDBACK)
(REFERENCE)
(FEEDBACK)
(RESET AND START)
(FREEZE REF AND START)
(RAMP 2)
(START-REF BIT 1)
(START-REF BIT 2)
(START-REF BIT 3)
Description of choice:
No function is selected if the FC motor is not to
react to signals transmitted to the terminal.
®
VLT FCM Series
332 333 334
2 3 4
[0] [0] [0]
[1] [1] [1]
[2] [2] [2]
[3] [3] [3]
[4] [4] [4]
[5] [5] [5]
[6] [6] [6]
[7] [7] [7]
[8] [8] [8]
[9] [9] [9]
[10] [10] [10]
[11] [11] [11]
[12] [12] [12]
[13] [13] [13]
[14] [14] [14]
[15] [15] [15]
[16] [16] [16]
[17] [17] [17]
[18] [18] [18]
[19] [19] [19]
[20] [20] [20]
[21] [21] [21]
[22] [22] [22]
[23]
[24]
[25]
[30]
[31]
[32] [32] [32]
[33] [33] [33]
[34] [34] [34]
[35] [35] [35]
[36] [36] [36]
[37] [37] [37]
335
5
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[32]
[33]
[34]
[35]
[36]
[37]
53
