Digital input
505-508 Bus
0 0
0 1
1 0
1 1
NB!:
Parameters 502-504 deal with stop functions
- see examples regarding 502 (coasting)
below. Active stop command "0".
Parameter 502 = Logic and
Digital input Bus
0 0
0 1
1 0
1 1
Parameter 502 = Logic or
Digital input Bus
0 0
0 1
1 0
1 1
509 Bus jog 1
(BUS JOG 1 FREQ.)
Value:
0.0 - parameter 202
10.0 HZ
Function:
This is where to set a fixed speed (jog) that is activated
via the serial communication port.
This function is the same as in parameter 213.
Description of choice:
The jog frequency f can be selected in the range
JOG
between f (parameter 201) and f
MIN
510 Bus jog 2
(BUS JOG 2 FREQ.)
Value:
0.0 - parameter 202
10.0 HZ
Function:
This is where to set a fixed speed (jog) that is activated
via the serial communication port.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.03.H3.02 - VLT is a registered Danfoss trademark
Control command
0
1
1
1
Control command
1 Coasting
0 Motor running
0 Motor running
0 Motor running
Control command
1 Coasting
1 Coasting
1 Coasting
0 Motor running
[0 -]
[100]
(parameter 202).
MAX
[0 -]
[100]
®
VLT FCM Series
This function is the same as in parameter 213.
Description of choice:
The jog frequency f can be selected in the range
JOG
between f (parameter 201) and f
MIN
512 Telegram profile
(TELEGRAM PROFILE)
Value:
Fieldbus Profile (FIELDBUS PROFILE)
FC Profile (FC PROFILE)
Function:
There is a choice of two different control word profiles.
Description of choice:
Select the desired control word profile.
See Serial communication for further information
about the control word profiles.
NB!:
This is only possible in Stop Mode (motor
stopped on a Stop command).
513 Bus time interval
(BUS TIMEOUT TIME)
Value:
1 - 99 sec.
1 sec.
Function:
This parameter sets the maximum time expected
to pass between the receipt of two consecutive
telegrams. If this time is exceeded, the serial
communication is assumed to have stopped and the
desired reaction is set in parameter 514.
Description of choice:
Set the desired time.
514 Bus time interval function
(BUS TIMEOUT FUNC)
Value:
Off (OFF)
Freeze output (FREEZE OUTPUT)
Stop (STOP)
Jogging (JOGGING)
Max. speed (MAX SPEED)
Stop and trip (STOP AND TRIP)
(parameter 202).
MAX
[0]
[1]
[1-99]
[1]
[0]
[1]
[2]
[3]
[4]
[5]
