340 Terminal 9, output functions (OUTPUT FUNC.)
Settings:
No function
Ready signal
Enable, no warning
Running
Running, no warning
Running on reference, no warning
Fault
Fault or warning
Current limit
Thermal warning
Reversing
Control word bit 11
Actual frequency 0-20 mA
Actual frequency 4-20 mA
Reference - reference
MIN MAX
Reference - reference
MIN MAX
Feedback - feedback
MIN MAX
Feedback - feedback
MIN MAX
Actual current 0-20 mA
Actual current 4-20 mA
Mechanical brake
Sleep mode
Function:
This output can act both as a digital and an
analogue output. If used as a digital output (data
value [0]-[20]), a 24 V DC signal is transmitted;
if used as an analogue output either a 0-20 mA
signal, or a 4-20 mA signal output.
Description of choice:
Unit Ready signal, the FC motor is ready for use.
Enable/no warning, the FC motor is ready for
use; no start or stop command has been given
(start/ disable). No warning.
Motor Running, the output frequency is higher than
0.1 Hz or a start command has been given.
Running no warning, the output frequency is higher than
0.1 Hz. A start command has been given. No warning.
Running on reference, no warning, speed according
to reference. No warning.
Fault, output is activated by alarm.
Fault or warning, the output is activated by
alarm or warning.
Current limit, the current limit in parameter
221 has been exceeded.
Thermal warning, above the temperature limit
in the frequency converter.
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.03.H3.02 - VLT is a registered Danfoss trademark
: 0-20 mA
: 4-20 mA
: 0-20 mA
: 4-20 mA
®
VLT FCM Series
(NO OPERATION)
(UNIT READY)
(ENABLE/NO WARNING)
(MOTOR RUNNING)
(RUNNING NO WARNING)
(RUNNING ON REFERENCE)
(FAULT)
(FAULT OR WARNING)
(CURRENT LIMIT)
(THERMAL WARNING)
(REVERSE)
(CONTROL WORD BIT 11)
(0-FMAX = 0-20 mA)
(0-FMAX = 4-20 mA)
(REF MIN-MAX =0-20 mA)
(REF MIN-MAX =4-20 mA)
(FB MIN-MAX =0-20 mA)
(FB MIN-MAX =4-20 mA)
(0-IMAX = 0-20 mA)
(0-IMAX = 4-20 mA)
(MECHANICAL BRAKE)
(SLEEP MODE)
Reverse. Logic '1' = relay activated, 24 V DC on the
output when the direction of rotation of the motor
is clockwise. Logic '0' = relay not activated, no
signal on the output, when the direction of rotation
of the motor is counter-clockwise.
Control word bit 11, if bit 11 = "1" in the control
word (both Fieldbus Profile and FC Profile) the
digital output will be activated.
⇒
0-fMAX (parameter 202)
⇒
0-fMAX (parameter 202)
Reference - Reference
MIN MAX
Reference - Reference
MIN
Feedback - Feedback
LOW HIGH
Feedback - Feedback
LOW
⇒
0-I 0-20 mA and
VLT, MAX
⇒
0-I 4-20 mA
VLT, MAX
Mechanical brake, enables control of an
optional external mechanical brake (see also
parameter 138 and 139).
Sleep mode, active when the unit is in sleep
mode. See sectionSleep mode.
