Product range

VLT DriveMotor FCM 300 Series, 2/4 poled motors
Type Motor output
FCM 305 0.55 kW
FCM 307 0.75 kW
FCM 311 1.1 kW
FCM 315 1.5 kW
FCM 322 2.2 kW
FCM 330 3.0 kW
FCM 340 4.0 kW
FCM 355 5.5 kW
FCM 375 7.5 kW
Each type in the product range is available
in different versions:
Inverter versions
Dri v e control:
- F00: Without Fieldbus
- F10: With PROFIBUS DP 3 MBit/s
- F12: With PROFIBUS DP 12MBit/s
RFI filter:
Inverter with integrated RFI filter, class 1A (industrial)
or class 1B (domestic).
Cooling:
- TEFV: Motor cooled by a shaft mounted fan (IC 411)
Mounting versions
- Foot mounting (B3)
- Flange mounting (B5)
- Face mounting (B14)
- Foot + flange mounting (B35)
- Foot + face mounting (B34)
See section Dimensions.
Inverter box position: Top, opposite motor feet.
Drainhole (+ position): None, D1, D2, D3 (see
drawing in section Ordering info for inverter box
position and drain hole position.

Ordering

Take a copy of the ordering form, see section
Ordering form. Fill in and post or fax your order
to the nearest branch office of the Danfoss sales
organisation. On the basis of your order, the FCM
300 Series motor is given a type code.
The ordering form for the basic unit must always be
completed. When the type code is written, always
state the characters of the basic string (1-34). Together
with the order confirmation the customer receives an
8-figure code number to be used when reordering.
MG.03.H3.02 - VLT is a registered Danfoss trademark
Mains supply
3 phase 380-480 V
®
VLT FCM Series
Danfoss PC software for serial communication, MCT 10
All FCM 300 Series units have an RS 485 port as
standard, which enables them to communicate e.g.
with a PC. A programme entitled MCT 10 is available
for this purpose (see section PC Software tools).
Ordering numbers, MCT 10
Please order your CD containing MCT 10 Set-up
Software using code number 130B1000.
PC Software - VLT Software Dialog
For single or few unit installations a basic software
package, VLT Software Dialog, is available. Please
order using code number 175Z0967.
Accessories for the FC motor
A Local Operation Pad (LOP) for local set point and
start/stop is available for the FC motor. The LOP is IP 66
enclosed. A Local Control Panel (LCP 2) which makes
up a complete interface for operation, programming
and monitoring of the FC motor is also available.
Ordering numbers, accessories
Local Operation Pad (LOP)
Local Control Panel (LCP 2)
Remote mounting kit (LCP 2)
Plug kit (LCP 2)
Cable for plug kit (LCP 2)
Cable (direct mounting) (LCP 2)
Service plug kit (LCP 2)
Potentiometer option
(Available from February 2005)
175N0128
175N0131
175N0160
175N2545
175N0162
175N0165
175N2546
177N0011
