Shaft Drive End
FCM 305 307
Frame size 80 80
D [mm] 19 19
E [mm] 40 40
ED [mm] 32 32
EB [mm] 4 4
DH [mm] M6x16 M6x16
F [mm] 6 6
GA [mm] 21.5 21.5
18
Shaft tapped
DH x deep to
DIN 332 Form DR
311 315 322
90 90 100
24 24 28
50 50 60
40 40 50
5 5 5
M8x19 M8x19 M10x22
8 8 8
27 27 31
®
VLT FCM Series
330 340
100 112
28 28
60 60
50 50
5 5
M10x22 M10x22
8 8
31 31
