User Manual
PT-PSW-41RS
Command Function
RS232 control mode 1: Control
50779% the far-end third-party device by
sending RS232 commands via PC,
RS232 control mode 2: Control
50780% the Scaler Switcher by sending
RS232 commands via PC.
IR control mode 1：Control the
50781%
far-end third-party device by
using its IR remote.
IR control mode 2: Control the
50782%
Scaler Switcher by using IR
remote.
Command Function
50772% EDID pass-through mode
50773% EDID 1080P
50774% EDID 1080P
50775% EDID 1080P3D
50776% EDID 1080I
50777% EDID 4K*2K
IR& RS232 Setup Commands
EDID Management Commands
2PCM
5.1
5.1
2PCM
2PCM
17
Feedback Example
RS232 Mode 1: Enable RS232
Control Remote
RS232 Mode 2: Disable RS232
Control Remote
IR Mode 1:IR Control Remote
IR Mode 2:IR Control Scaler
Feedback Example
EDID:bypass mode
EDID:1080P&PCM 2ch
EDID:1080P&5.1ch
EDID:1080P3d&5.1ch
EDID:1080i&PCM 2ch
EDID:4K&PCM 2ch
