User Manual
PT-PSW-41RS
Command Function
Pull right from left side (decrease
50675%
image width)
Stretch upwards from bottom side
50676%
(decrease image height)
Stretch downwards from bottom
50677%
side (increase image height)
Change the horizontal polarity to
50705%
the opposite
Change the vertical polarity to the
50706%
opposite
Command Function
50631% Check the current input source
50632% Check the output resolution
50633% Check the image mode
50635% Check the image aspect ratio
50636% Check the brightness
50637% Check the contrast
50638% Check the saturation
50639% Check sharpness
50640% Check the color temperature
Image adjustment Commands
Inquire Commands
19
Feedback Example
Output Width Adjust xx
Output Height Adjust xx
Output Height Adjust xx
Hpolarity:0/1
Vpolarity:0/1
Feedback Example
Input: xx (xx= HDMI/ DP/ DVI/ VGA)
Resolution: xx (xx=1920×1200/
1920×1080/1360×768/
1280×800/ 1280×720/ 1024×768)
Picture Mode: xx (xx= Dynamic/
Standard/ Mild/ User)
Aspect Ratio: xx (xx= 16:9/ 4:3/
auto)
Brightness: xx (xx=00~99)
Contrast: xx (xx=00~99)
Saturation: xx (xx=00~99)
Sharpness: xx (xx=00~99)
Color Temperature: xx
(XX= Cool/ Medium/ Warm/ User.)
