Specifications
6 6
Illustration 6.11 Connector Position
CAUTION
Never turn the CleanConnect plug more than 45° clockwise or anti-clockwise from the delivered middle axis (0°) as shown in
Illustration 6.11.
If the plug is rotated more then the permitted 45°, the cables could be damaged, causing a short-circuit.
6.6.4 VLT ®
Illustration 6.12 Torque Arm in Front Position
26
OneGearDrive Hygienic with Torque Arm in Front Position (optional)
207.5 147
185
25
MG75C302 - VLT
®
VLT OneGearDrive Operating Instructions
78.5
®
is a registered Danfoss trademark
92.5
35
6
1
123
