Assembly Kit - Danfoss VLT OneGearDrive Operating Instructions Manual

Installation

2.5 Assembly Kit

2 2
6 1
Illustration 2.1 Assembly Kit
1 Shaft
2 Disc
3 Retaining ring
4 Lock washer
5 Fixing screw (filister head)
6 Key
Table 2.1 Legend to Illustration 2.1
Type
OGD-30
OGD-35
OGD-40
Table 2.2 Dimensions
1) Key length required for b
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
8
VLT
3 2 4
Holding
Retaining ring (3) Lock washer (4)
DIN 472
30x1.2
35x1.5
40x1.75
in Table 2.3. Adapt the key length according to the shaft length used (b) in Table 2.3.
min
MG75C302 - VLT
®
OneGearDrive Operating Instructions
5
Dimensions [mm]
Fixing screw (5)
DIN 7980 DIN 912-8.8
10 M10x30
12 M12x35
16 M16x35
®
is a registered Danfoss trademark
Key (6)
DIN 6885
Width x Height x Length
1)
A 8x7x100
1)
A 10x8x100
A 12x8x100 1)
