Mechanical Installation

3.6 Assembly Kit

6 1 3
Holding
1 Shaft
2 Disc
3 Retaining ring
4 Lock washer
5 Fixing screw (filister head)
6 Key
Illustration 3.2 Assembly Kit
Type
Retaining ring (3)
DIN 472
OGD-30 30x1.2
OGD-35 35x1.5
OGD-40 40x1.75
Table 3.2 Dimensions of Assembly Kit Items
1) Key length required for b in Table 3.3. Adapt the key length according to the shaft length used (b) in Table 3.3.
min
The dimensions shown could differ from the customer conditions and must potentially be changed by the customer.
MG75C402
Operating Instructions
2 4 5
Dimensions [mm]
Lock washer (4)
DIN 7980
10
12
16
Danfoss A/S © 06/2014 All rights reserved.
Fixing screw (5)
DIN 912-8.8
Width x Height x Length
M10x30
M12x35
M16x35
Key (6)
DIN 6885
A 8x7x100 1)
1)
A 10x8x100
1)
A 12x8x100
9
3 3
