WATER SUPPLY AND DRAIN CONNECTIONS / FINAL CHECKLIST / STARTUP
An air gap of a minimum of 2 vertical inches (5 cm) must be
between the end of the drain pipe from the appliance and the
floor drain.
For gravity drain installation, drain must have 1/4" fall per foot
(2 cm per 1 m) on horizontal runs to get good flow. A vented
tee connection is also required for proper flow. Extend the vent
at least 12" (30 cm) above the drain outlet. For optional drain
pump (63802A) installation, refer to the instructions included
with the pump.

FINAL CHECKLIST

DANGER
CHOKING HAZARD: Ensure all components,
!
fasteners, and thumbscrews are securely in place after
installation. Make sure that none have fallen into the
storage bin.
1. Is the appliance level?
2. Is the appliance in a site where the ambient temperature
is within 45°F to 100°F (7°C to 38°C) and the water
temperature within 45°F to 95°F (7°C to 35°C) all year
around?
3. Have the shipping carton, tape, and packing material been
removed from the appliance? Has the protective plastic
film been removed from the panels?
4. Have all electrical and water connections been made? Do
electrical and water connections meet all national, state,
and local code and regulation requirements?
5. Has the power supply voltage been checked or tested
against the nameplate rating? Is the power supply a
properly grounded, independent 3-prong wall outlet?
6. Are the water supply and drain lines sized as specified?
Are the water supply line shut-off valve and drain valve
installed? Has the water supply pressure been checked to
ensure a minimum of 10 PSIG and a maximum of 113 PSIG?
7. Are all components, fasteners, and thumbscrews securely
in place?
8. Has the end user been given this instruction manual,
and instructed on how to operate the appliance and the
importance of the recommended periodic maintenance?
9. Has the end user been given the name and telephone
number of an authorized service agent?
10. Has the warranty tag been filled out and forwarded to the
factory for warranty registration?
20 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL

STARTUP

DANGER
All parts are factory-adjusted. Improper
!
adjustments may adversely affect safety, performance,
component life, and warranty coverage.
WARNING
If the appliance is turned off, wait for at least
3 minutes before restarting the appliance to prevent damage to
the compressor.
WARNING
At startup, confirm that all internal and
external connections are free of leaks.
1. Open the water supply line shut-off valve.
2. Make sure the control switch is in the "OFF" position. Plug
the appliance into the electrical outlet.
DANGER
To reduce the risk of electric shock, do not
!
touch the control switch or plug with damp hands. If you
have to slide the appliance back for a built-in installation,
make sure you do not damage or pinch the water supply line,
drain line, or power cord.
3. If required by sanitation code in your area, seal the
perimeter where the appliance touches the floor with
approved caulk compound in a smooth and easily cleanable
manner.
4. Move the control switch to the "ICE" position to start the
automatic ice making process.
5. Once the appliance starts to produce ice, allow it to run for
another 30 minutes.
6. Move the control switch to the "OFF" position.
